Marshall Electronics VS-M226-A 2.2-6mm f1.3 Fujinon Varifocal Lens, DC Auto-Iris, CS Mount

OUR PART #: VS-M226-A MFR #: BAV-VS-M226-A

Copied to clipboard

Marshall Electronics' VS-M226-A is a 2.2-6mm Fuijinon CS Varifocal lens with DC Auto-Iris. ...Read more

Marshall Electronics VS-M226-A 2.2-6mm F1.3 Fujinon Varifocal Lens, DC Auto-Iris, CS Mount Image 1
Marshall Electronics VS-M226-A 2.2-6mm F1.3 Fujinon Varifocal Lens, DC Auto-Iris, CS Mount
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Product Overview

Marshall Electronics' VS-M226-A is a 2.2-6mm Fuijinon CS Varifocal lens with DC Auto-Iris.

Marshall Electronics VS-M226-A Specifications:

  • Focal Length (mm): 2.2 - 6 (2.7x)
  • Iris Range: F1.3 - T360
  • Zoom: Manual
  • Focus: Manual
  • Iris: Auto (DC type)
  • Angle Of View (H×V):
    • 1/2.7":
      • Wide: 132°51' × 100°22'
      • Tele: 50°26' × 37°56'
    • 1/3":
      • Wide: 121°4' × 91°20'
      • Tele: 45°51' × 34°28'
    • 1/4":
    • Wide: 91°20' × 68°43'
    • Tele: 34°28' × 25°53'
  • Angle Of View (H×V) Aspect Ratio 16:9:
    • 1/2.7":
      • Wide: 144°17' × 82°13'
      • Tele: 54°53' × 31°1'
    • 1/3":
      • Wide: 131°34' × 74°46'
      • Tele: 49°55' × 28°11'
    • 1/4":
    • Wide: 99°19' × 56°19'
    • Tele: 37°31' × 21°12'
  • Focusing Range (From Front Of The Lens)(m) - 0.3
    • Object Dimensions at M.O.D.(H×V) (mm):
    • 1/2.7":
      • Wide: 1398 × 731
      • Tele: 299 × 218
    • 1/3":
      • Wide: 1080 × 625
      • Tele: 269 × 197
    • 1/4":
    • Wide: 625 × 417
    • Tele: 197 × 146
  • Object Dimensions at M.O.D.(H×V) (mm) Aspect Ratio 16:9:
      • 1/2.7":
        • Wide: 1896 × 532
        • Tele: 329 × 176
      • 1/3":
        • Wide: 1358 × 466
        • Tele: 296 × 159
      • 1/4":
      • Wide: 718 × 327
      • Tele: 216 × 119
    • Back Focal Distance (in air)(mm): 8.33
        • Exit Pupil Position (From Image Plane)(mm): 116
        • Mount: CS
        • Mass: 80g
        • Coil Resistance:
          • Drive Coil 190
          • Damping Coil 500
        • Current Consumption: 23mA (Max.) at DC 4V
