Liberty AV Solutions 12-2C-EX+WHT-250
Conductor Heavy Duty Speaker Cable, 250ft

OUR PART #:  12-2C-EX+WHT-250

The Liberty AV Solutions 12-2C-EX+-WHT is 250 ft heavy duty speaker cable.
Learn More
Our Price: $232.20
List Price: $258.00
You save 10%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Liberty AV Solutions 12-2C-EX+WHT-250
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The Liberty AV Solutions 12-2C-EX+-WHT is 250 ft heavy duty speaker cable. This speaker cable features a 2 conductor 12 AWG stranded, twisted, and unshielded cable NEC type CL3 and CEC type CMG FT4 for Audio Only. Product manufactured compliant to the requirements of UL13 for installations and applications in accordance with NEC article 725.

Liberty AV Solutions 12-2C-EX+WHITE-250 Features:

  • 105 Strand Oxygen Free Copper conductors
  • Semi-Rigid PVC Insulation
  • Twisted, Unshielded
  • EZ-Strip paper tape binder with optional ripcord
  • Pressure Extruded PVC Jacket for optimal roundness
  • UL13 CL3 and CMG FT4 for in-wall applications
  • RoHS Compliant

Liberty AV Solutions 12-2C-EX+WHT-250 Specifications:

  • Conductor:
    • 12 AWG
    • 105-strand oxygen free copper conductors
    • Diameter: 0.093" (2.36 mm)
  • Electrical:
    • DC resistance: 1.58 Ohm / 1000’ (5.18 Ohm / KM)
    • Mutual capacitance: 34.0 pF / FT (111.52 pF / M)
    • Impedance: 60 Ohm
    • Inductance: 0.17 µH / FT (0.55 µH / M)
    • Velocity of Propagation: 55 %
    • Voltage rating: 300 V
    • Maximum current: 9.6 A @ 25° C
  • Insulation:
    • Semi-rigid polyvinyl chloride
    • Wall thickness: 0.016" (0.42 mm)
    • Diameter: 0.126" (3.2mm)
  • Regulatory:
    • NEC: CL3 75°C
    • CEC: CMG FT4 For Audio Only 60°C
    • EU RoHS-2 2011 / 65 / EU Compliant
    • Color Code: Black, Red
  • Packages:
    • Reel: 500’ (152 M)
    • Weight: 90 Lbs/1000’ (135 Kg / KM)
  • Assembly:
    • 2 conductors twisted
    • Lay length: 3.0" (80 mm)
    • 4.0 twists per foot (12.5 twists per meter)
  • Installation:
    • Pull Tension: 106 lbs (472 N)
    • Bend radius: 3.27" (83 mm unloaded)
    • Bend radius: 6.54" (166 mm loaded)
  • Construct:
    • 100% Paper tape binder
    • Ripcord under jacket
  • Applications:
    • General purpose speaker level audio
    • General purpose 70V commercial speaker audio
    • General purpose Class 2 and 3 power
  • Performance:
    • Speaker level audio to 120 ft
  • Jacket:
    • Pressure extruded polyvinyl chloride
    • Colors: Teal, White
    • Wall thickness: 0.036" (0.91 mm)
    • Diameter: 0.327" (8.30 mm)
  • Final Outside Diameter (inches): 0.327
