OUR PART # MIP1S
The Whirlwind MIP1 is a 2-gang wallplate featuring RCA and 3.5mm stereo input jacks, an additional speaker input terminated with a 16 Ohm load resistor, plus an integrated mono version of Whirlwind's pcDI computer interface device. Its line and speaker inputs are summed together then sent to the Dimax transformer which balances the output signal, attenuates it by 20 dB, and converts it to Low-Z mic level to be output via rear-mounted screw terminals. An onboard Ground Lift switch allows you to break the ground connection between the inputs and the output screw terminal. Also, the MIP1 plates have an additional female XLR to provide for the connection of a separate mic channel to the plate. This particular model comes in a stainless steel finish, with a black anodized aluminum finish version available separately (contact your Sales Pro for more information).
The Whirlwind MIP Series
Variations of some of Whirlwind's most popular DI boxes, the MIP1, MIP2, and MIP3 media input plates are available in standard gang plate sizes, and are designed for permanent installation in churches, banquet halls, conference rooms, and many other applications. These wallplates employ the Whirlwind Dimax transformer, providing superior sonic transparency and low noise. The rear output connections are 3.5mm screw type removable plugs (Phoenix® 1984329 or equivalent).
