Tannoy VXP8WH 8" Compact 2-Way Dual-Concentric Powered Speaker, White

OUR PART #: VXP8-WHITE MFR #: TA-VXP8-WH

Copied to clipboard

Conceived, engineered and built with precision in the United Kingdom... ...Read more

Tannoy VXP8WH 8" Compact 2-Way Dual-Concentric Powered Speaker, White Image 1
Tannoy VXP8WH 8" Compact 2-Way Dual-Concentric Powered Speaker, White Image 2
Tannoy VXP8WH 8" Compact 2-Way Dual-Concentric Powered Speaker, White
Our Price: $979.00
Synchrony Music & Sound Card
No Interest if paid in full within 6 Months
Learn How
Item usually available to ship in 9-12 Business Days. Please call for up-to-date information on product availability.
This item can only be purchased in quantities of 2

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

Conceived, engineered and built with precision in the United Kingdom, the VXP Series represents a brand new evolution in Tannoy’s core philosophies in self-powered loudspeaker design.

The Tannoy VXP 8 combines the technological refinement of the passive VX 8 with the brand new IDEEA™ integrated power module from Lab.gruppen. The result is a highly compact, ultra-reliable and efficient, self-powered loudspeaker offering a punchy and sonically superior solution for small-scale sound reinforcement and high performance speech reproduction where clarity and vocal character are paramount. The VXP 8 has also been acoustically matched with the wider range of VXP Series models, making it a perfectly capable component within much larger installations.

The integrated Lab.gruppen IDEEA (IntelliDrive Energy Efficient Amplifier) modules are designed to handle the demands of fixed installation audio, with the inherent extended duty cycles of around-the-clock operation and very high performance demands, while offering the durability, unmatched power output and clarity required by portable applications. To ensure a long and trouble-free service life, IDEEA modules incorporate extensive features to safeguard internal circuits and driver complement.

At the heart of the IDEEA module is a patented Class D output stage capable of high power levels with very low distortion and minimal current draw – all with a net operating efficiency in excess of 80%. A universal switching power supply accepts any mains voltage from 70 – 265 V (+/- 10%) at 50 Hz or 60 Hz through the appropriate IEC cord. In Auto mode, the speaker turns on with signal present and switches to standby mode after 20 minutes of no input, in doing so reducing power consumption to less than 1 W (while in standby). Manual control mode allows the speaker to be turned on and off as required. Also provided is a switchable 90 Hz high-pass filter for use when adding a subwoofer.

Audio connection is via female XLR and power via PowerCON (included) on the rear panel. The VXP 8 is available in black or white textured paint finish as standard, with matching grilles, and is also available in custom matched RAL colours as an option.

Tannoy VXP8 Features:

  • 200 mm (8”) Dual Concentric full-range driver
  • Well defined 90 degree dispersion for optimum coverage and forward gain
  • Peak output of 120 dB
  • Integrated Lab.gruppen IDEEA module providing ultra-reliable Class D amplification
  • Versatile mounting via optional custom-designed hardware
  • Pole-mountable for small-scale portable PA applications
  • Exceptional sound and performance for a cabinet of this size
  • Rugged and highly compact birch plywood enclosure
  • Available in black or white textured paint finish; custom colors optional
  • XLR input and link, powerCON mains (included)

Tannoy VXP 8 Specifications:

  • Performance:
    • Frequency Response: (-3 dB) (1)
    • Full Range Mode: 80 Hz - 35 kHz
    • Frequency Range: (-10 dB) (1)
    • Full Range Mode: 67 Hz - 45 kHz
    • Frequency Response: (-3 dB) (1)
    • High Pass Mode: 120 Hz - 35 kHz
    • Frequency Range: (-10 dB) (1)
    • High Pass Mode: 100 Hz - 45 kHz Dispersion (-6 dB): 90 degrees conical
    • Driver Complement: 1 x 200 mm (8.00") constant directivity Dual Concentric™
    • Crossover: Passive 1.7 kHz with dynamic HF protection
    • Directivity Factor (Q): 6.8 averaged 1 kHz to 10 kHz
    • Directivity Index (DI): 7.9 averaged 1 kHz to 10 kHz
    • Rated Maximum SPL (2):
      • Average: 114 dB
      • Peak: 120 dB
    • Distortion:
    • 10% Full Power (8.94 V):
      • 2nd Harmonic 250 Hz: 0.12%, 1 kHz: 0.23%, 10 kHz: 1.35%
      • 3rd Harmonic 250 Hz: 0.15%, 1 kHz: 0.84%, 10 kHz: 0.16%
    • 1% Full Power (2.83 V):
      • 2nd Harmonic 250 Hz: 0.16%, 1 kHz: 0.09%, 10 kHz: 0.53%
      • 3rd Harmonic 250 Hz: 0.14%, 1 kHz: 0.53%, 10 kHz: 0.17%
    • Amplifier:
      • Maximum signal input for clip: Input attenuator at Maximum: +4.5 dBu (Hard clip will occur at 14.5 dBu input signal)
      • Dynamic Range: 106 dB
      • Efficiency: >90%
      • Damping Factor: >400 ref 8 ohm at 1 kHz
      • Distortion: < 0.05% @ 1 kHz - 3 dB output (22 kHz bandwidth)
      • Input Impedance: 10 kOhms (unbalanced) 20 kOhms (balanced)
    • PSU Specifications:
      • Input Connector: Locking Neutrik Powercon
      • Voltage Selection: Universal mains input
      • System Type: High efficiency, regulated switch mode power supply
      • Efficiency: >85% typical
      • Input voltage: 100 Vac - 240 Vac +/- 10%, 50 - 60 Hz +/-10%
      • Mains fuse: Internal
      • Fuse type: 3.15AT
      • Other features: Inrush current limiter
      • Standby power consumption: < 1 W
      • Idle power consumption: < 15 W
      • Maximum power consumption: 300 W
    • Protection Systems:
    • Over Current: Output current limiter, always active
    • Clip limiter: Output voltage clip limiter, always active
    • Temperature: Over temperature causes protective mute
    • Brownout: Automatic protection & recovery
    • Mains: Inrush current limiter
    • Indicators:
      • 1 x Power LED
      • 1 x Signal LED
      • 1 x Limit LED (Power LED: Red = Standby, Green =On, Yellow = Temperature protection active)
    • Amplifier Type: Inherently bridged, globally modulated, high performance single channel class D
  • Construction:
    • Enclosure: 16.3 litre, 15 mm (0.62") birch plywood, vented and internally braced
    • Finish:
      • Textured black or white paint (custom colours on request)
      • Powder coated perforated steel grille
      • Airnet cloth behind
    • Connectors:
      • 1 x female XLR (input)
      • 1 x male XLR (link)
      • 1 x Neutrik Powercon
    • Controls and Indicators:
      • Level Control
      • Power LED (Blue)
      • Signal LED (Green)
      • Limit/Protect LED (Red)
      • Full Range / HighPass Switch (110 Hz)
      • Power Mode Switch
      • Power Switch
    • Fittings:
      • 2 x M10 flying inserts
      • 2 x M10 yoke bracket inserts (6 mm allen key)
      • Blanking plate for optional VTH pole mount
    • Dimensions (H x W x D): 388 x 280 x 275 mm (15.13" x 10.92" x 10.73")
    • Net Weight (ea): 10 kg (22 lbs)
    • Shipping Weight: 21.5 kg (47.4 lbs)
    • Packed Quantity: 2

Note:

Product is WHITE in Apperance
