TV One C2-8110
Seamless Switcher

OUR PART #  C2-8110

Call for price! Not available online.
List Price: $5,850.00


C2-8000 Series multi-format products offer the ultimate flexibility for switching and scaling a wide range of analog and digital video signals. CORIO2 or C2- based products provide the benchmark for video image conversion products, coming nearer the ideal of "Anything In - Anything Out" than any other conversion products on the market.

TV One Seamless Switcher Includes:

  • SDTV/HDTV Conversion
  • Digital/Analog Conversion
  • Aspect Ratio Conversion
  • Up/Down-Conversion
  • Video Scaling
  • Multi-Format Seamless Switching
  • Worldwide Standards Conversion
  • Chroma/Lumakeying
  • Picture-in-Picture Windowing
  • TBC/Frame Synchronization

TV One Seamless Switcher Features:

  • 1RU size
  • High quality seamless switching
  • Up-Down-Cross Conversion
  • DVI-U inputs (HDMI/CV/YC/RGB/YPbPr): up to 12
  • SDI inputs: up to 2 SD/HD/3G-SDI + re-clocked out
  • DVI-U outputs: 2 (HDMI/CV/YC/RGB/YPbPr)
  • SDI outputs: up to 2 (SD/HD/3G)
  • Genlock inputs: 1x Tri/Bi with loop-through
  • Analog: PC to 2048x2048, HDTV to 1080p/60
  • DVI: PC to 1920x1200, HDTV to 1080p/60
  • Supports: NTSC, PAL, PAL-M, PAL-N, SECAM
  • HDMI-compatible input & output with HDCP
  • Motion Compensation & 3:2 Pull-down
  • Diagonal Interpolation
  • Noise Reduction for PAL, NTSC and 1080i inputs
  • Automatic Incoming Resolution Detection
  • AutoSet - Automatic picture sizing of PC inputs
  • 4:4:4 Full bandwidth sampling
  • Variable Image Zoom to 10X and Shrink to 10%
  • Chroma and Luma keying
  • Fade, Wipe, Push, Cut transitions
  • Video signal parameter adjustments
  • Audio de-embed / embed for SDI and DVI
  • Closed-caption de-embed / embed for CV / SDI
  • Integral Audio Routing
  • User-defined Logo insertion
  • Still image store
  • Borders with variable size and colour
  • IP Interface
  • RS-232/422/485 interface
  • Optional Audio Module with AES break-out and adjustable delay
  • Optional Tally Module
  • Optional Redundant Power Supplies

TV One Seamless Switcher Specifications:

  • Video Inputs:
    • Television Standards: NTSC, PAL, PAL-M/N, SECAM
    • Composite Video: Up to 6x via DVI-U
    • YC (S-Video): Up to 6x via DVI-U
    • YUV /YPbPr: Up to 6x via DVI-U
  • Computer Inputs:
    • Digital DVI  (HDMI & HDCP compatible): Up to 6x via DVI-U
    • Analog: Up to 6x via DVI-U
    • Analog Format: RGBHV, RGBS, RGsB, YPbPr
    • Analog Signals: PC to 2048x2048, HD to 1080p60
    • DVI Signals: PC to 1920x1200, HD to 1080p60
  • Video Outputs:
    • Television Standards: NTSC, PAL, PAL-M/N, SECAM
    • Composite Video: 2x via DVI-U
    • YC (S-Video): 2x via DVI-U
    • YUV /YPbPr: 2x via DVI-U
  • Computer Outputs:
    • DVI Signals  (HDMI & HDCP compatible): 2x via DVI-U
    • Analog: 2x via DVI-U
    • Analog format: RGBHV, RGBS, RGsB, YPbPr
    • DVI Signals: PC to 1920x1200, HD to 1080p60
    • Analog Signals: PC to 2048x2048, HD to 1080p60
  • Audio support: De-embed / embed HDMI-I/O via DVI
  • Control Methods:
    • Front Panel Buttons & LCD
    • RS-232/422/485
    • IP Interface
  • Limited Warranty: 5 Years Parts and Labor
  • Mechanical:
    • Size (H x W x D): 1.73” x 17.0” x 13.1” (44 x 431 x 334mm)
    • Weight (Net): Approx. 5Kg

TV One C2-8110
Seamless Switcher

OUR PART #  C2-8110

Product Information:

C2-8000 Series multi-format products offer the ultimate flexibility for switching and scaling a wide range of analog and digital video signals. CORIO2 or C2- based products provide the benchmark for video image conversion products, coming nearer the ideal of "Anything In - Anything Out" than any other conversion products on the market.

TV One Seamless Switcher Includes:

  • SDTV/HDTV Conversion
  • Digital/Analog Conversion
  • Aspect Ratio Conversion
  • Up/Down-Conversion
  • Video Scaling
  • Multi-Format Seamless Switching
  • Worldwide Standards Conversion
  • Chroma/Lumakeying
  • Picture-in-Picture Windowing
  • TBC/Frame Synchronization

TV One Seamless Switcher Features:

  • 1RU size
  • High quality seamless switching
  • Up-Down-Cross Conversion
  • DVI-U inputs (HDMI/CV/YC/RGB/YPbPr): up to 12
  • SDI inputs: up to 2 SD/HD/3G-SDI + re-clocked out
  • DVI-U outputs: 2 (HDMI/CV/YC/RGB/YPbPr)
  • SDI outputs: up to 2 (SD/HD/3G)
  • Genlock inputs: 1x Tri/Bi with loop-through
  • Analog: PC to 2048x2048, HDTV to 1080p/60
  • DVI: PC to 1920x1200, HDTV to 1080p/60
  • Supports: NTSC, PAL, PAL-M, PAL-N, SECAM
  • HDMI-compatible input & output with HDCP
  • Motion Compensation & 3:2 Pull-down
  • Diagonal Interpolation
  • Noise Reduction for PAL, NTSC and 1080i inputs
  • Automatic Incoming Resolution Detection
  • AutoSet - Automatic picture sizing of PC inputs
  • 4:4:4 Full bandwidth sampling
  • Variable Image Zoom to 10X and Shrink to 10%
  • Chroma and Luma keying
  • Fade, Wipe, Push, Cut transitions
  • Video signal parameter adjustments
  • Audio de-embed / embed for SDI and DVI
  • Closed-caption de-embed / embed for CV / SDI
  • Integral Audio Routing
  • User-defined Logo insertion
  • Still image store
  • Borders with variable size and colour
  • IP Interface
  • RS-232/422/485 interface
  • Optional Audio Module with AES break-out and adjustable delay
  • Optional Tally Module
  • Optional Redundant Power Supplies

TV One Seamless Switcher Specifications:

  • Video Inputs:
    • Television Standards: NTSC, PAL, PAL-M/N, SECAM
    • Composite Video: Up to 6x via DVI-U
    • YC (S-Video): Up to 6x via DVI-U
    • YUV /YPbPr: Up to 6x via DVI-U
  • Computer Inputs:
    • Digital DVI  (HDMI & HDCP compatible): Up to 6x via DVI-U
    • Analog: Up to 6x via DVI-U
    • Analog Format: RGBHV, RGBS, RGsB, YPbPr
    • Analog Signals: PC to 2048x2048, HD to 1080p60
    • DVI Signals: PC to 1920x1200, HD to 1080p60
  • Video Outputs:
    • Television Standards: NTSC, PAL, PAL-M/N, SECAM
    • Composite Video: 2x via DVI-U
    • YC (S-Video): 2x via DVI-U
    • YUV /YPbPr: 2x via DVI-U
  • Computer Outputs:
    • DVI Signals  (HDMI & HDCP compatible): 2x via DVI-U
    • Analog: 2x via DVI-U
    • Analog format: RGBHV, RGBS, RGsB, YPbPr
    • DVI Signals: PC to 1920x1200, HD to 1080p60
    • Analog Signals: PC to 2048x2048, HD to 1080p60
  • Audio support: De-embed / embed HDMI-I/O via DVI
  • Control Methods:
    • Front Panel Buttons & LCD
    • RS-232/422/485
    • IP Interface
  • Limited Warranty: 5 Years Parts and Labor
  • Mechanical:
    • Size (H x W x D): 1.73” x 17.0” x 13.1” (44 x 431 x 334mm)
    • Weight (Net): Approx. 5Kg
