Inter-M Americas MA-110N Mixing Amplifier With 100 Watts

OUR PART #: MA-110N MFR #: MA-110

Copied to clipboard

Inter M America MA-110N is a 1U-sized compact size Public Address Amplifier that suits small venues such as a conference room, multi-purpose hall, restaurant, and cafe. ...Read more

Inter-M Americas MA-110N Mixing Amplifier With 100 Watts Image 1
Inter-M Americas MA-110N Mixing Amplifier With 100 Watts Image 2
Inter-M Americas MA-110N Mixing Amplifier With 100 Watts
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Product Overview

Inter M America MA-110N is a 1U-sized compact size Public Address Amplifier that suits small venues such as a conference room, multi-purpose hall, restaurant, and cafe. With its high efficient amplifier circuit, MA-110 (N) is light weight and low heat. Plus, additional functions such as input of MIC and LINE, tone control, mute, priority function, Auto Sleep Mode and Phantom microphone power are possible with our compact MA-106 (N) / 110 (N).

Inter-M Americas Inc MA-110 Features:

  • Digital Amplifier Circuit
  • SMPS Power Supply Circuit
  • Auto Sleep Mode
  • Tone controller (Bass / Treble)
  • Outside Mute Control
  • Additional Function
  • Compact Design

Inter-M Americas Inc MA-110 Specifications:

  • Rated Output: 100 W
  • Speaker Output/Impedance: 100 V 100 Ohms, 70 V / 49 Ohms
  • Sensitivity/impedance:
    • INPUT 1: -50 dBV / 2 k Ohms
    • INPUT 2 (MIC): -50 dBV / 2 k Ohms
    • INPUT 2 (LINE): -10 dBV / 20 k Ohms
    • INPUT 3: -10 dBV / 10 k Ohms
    • TEL IN: 0.775 V / 600O
  • Frequency Response: 80 Hz ~ 15 kHz
  • THD: Less than 1 % at 60 W
  • Signal-to-Noise ratio:
    • INPUT 1, 2: Better than 60 dB
    • INPUT 3, TEL IN: Better than 70 dB
  • Tone Control:
    • BASS (100Hz): +/- 12 dB
    • TREBLE (10 kHz): +/- 12 dB
  • Operating Temperature: Approximately -10°C to +40°C
  • Power source: AC100 V - 120 V / 220 V - 240 V, 50 / 60 Hz
  • Dimension (W x H x D) (set): 300 x 44 x 23 mm
