Draper 114228 147.5" x 236" Paragon E Matt White Electric Projection Screen

The Draper 114228 is part of their Paragon/Series E heavy-duty electric projection screens. It features a Matt White XT1000E screen surface, and uses 110V for operation. These screens are ideal for lecture halls and auditoriums, or for any setting where a very large screen is required. The motor is installed on special vibration insulators inside a 6" (152mm) diameter steel roller so operation is quiet, smooth, and reliable. The case is constructed of white extruded aluminum and can be suspended anywhere, with controls set wherever you might need.

The Matt White XT1000E Surface is the standard to which all other screen surfaces are measured, and is the preferred viewing surface in commercial and educational markets. A matt white surface diffuses projected light in all directions, making the image visible from virtually any angle. This surface delivers accurate color rendition and exceptional clarity via its smooth, non-embossed surface. It requires adequate provision for the control of ambient light in the audience area. Provides unity gain with a panoramic 180° cone. Matt White XT1000E Surface is GREENGUARD Children and SchoolsSM certified.

Draper 114228 Paragon/Series E Specifications:

• Part number: 114228
• Surface material: Matt White XT1000E
• Image Format: 16:10
• Diagonal size: 278"
• Image/Viewable area: 147-1/2" x 236" (375 x 599cm)
• Operating Voltage: 110V
• Overall size: 152-1/2" x 240" (387 x 610cm)
• Case length: 250" (635cm)
• Product weight: 440 lbs (200 kg)
• Shipping weight: 775 lbs (352 kg)
• Matt White XT1000E Surface Characteristics
  • Maximum Height Without Seams: 120"
  • Weight (g/sm): 515
  • Weight (oz/yd²): 15.19
  • Thickness (mm): 0.38
  • Cleaning: Mild soap and water
  • Flame Retardant: NFPA-701
  • Composition: Fiberglass base laminated with PVC. Composition may differ slightly for some screen sizes/models.
  • Gain On Axis/0° Gain: 1
  • Half Gain Angle: Material does not reach half gain.
