Neumann KH805/KH120 Bundle
Pair of 2-Way Active Near-field Reference Monitors w/ 10" Active Studio Subwoofer

OUR PART #:  KH805/KH120-BUNDLE

The Neumann KH 805/KH 120 A Bundle is a pair of 2-way, 5.25"+1", active near-field reference monitors (KH 120 A) with an analog controller...
Learn More
Our Price: $2,997.00

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Neumann KH805/KH120 Bundle
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The Neumann KH 805/KH 120 A Bundle is a pair of 2-way, 5.25"+1", active near-field reference monitors (KH 120 A) with an analog controller, electronically-balanced input and US mains cable, combined with a 10" active studio subwoofer (KH 805) that has a 2.0 / 0.1 Bass Manager.

The KH 805 is a 10", 200-watt active studio subwoofer whose 4-mode operation is tailored for a wide variety of uses, and with much installation flexibility. It is based on the acoustic performance of the KH 810 subwoofer - also an optimal choice for stereo set-ups - and works especially well in combination with the KH 120 or KH 310 loudspeakers for tracking, mixing and mastering in recording, broadcast, or post-production studios.

The unit's solid, well-braced cabinet construction has a feature set of its own, such as extremely low tuning frequency to minimize unwanted resonance; a long excursion, low-distortion, magnetically shielded 10" driver; high efficiency, low-heat dissipation power amplification techniques, and electronics that can be remote located (REK 3) for reduced cabling and ease of use.

This subwoofer can be used as bass extension for loudspeakers down to 18 Hz, to increase the maximum SPL of loudspeakers by up to 8 dB, to decrease harmonic and intermodulation distortion of loudspeakers, to reproduce the LFE channel, to reproduce the "sub" signal of a bass managed multichannel source, to make a Plane Wave Bass Array™ system (increased low frequency linearity), or work as an extension for KH 810, KH 870 and KH 805 subwoofer systems.

The 2.0 / 0.1 Bass Manager of the KH 805 can be used for stereo and multichannel applications like bass management with 4th order, 80 Hz crossover (compatible with typical systems). It can also be bypassed using a simple switch or footswitch. Acoustic controls that contribute to installation flexibility include output level, low cut, parametric EQ, and a 45° step phase control. Last but not least, the right input connector has four routing modes: right channel bass management, LFE to subwoofer (up to 120 Hz), wide for multichannel systems where bass management is in the source and daisy chain for subwoofer arrays.

KH 120 A studio monitors are designed for use as a near-field loudspeaker or as a rear loudspeaker in larger multi-channel systems. The KH 120 A represents the latest in acoustic technologies, highlighted by its Mathematically Modeled Dispersion (MMD)™ waveguide, flexible acoustical controls, analog class-AB amplifiers, a large headroom analog input and an extensive mounting hardware range. These provide the user with maximum versatility over a wide variety of acoustic conditions, source equipment, and physical locations.

An MMD™ waveguide gives a smoother off-axis response that is more forgiving of diverse acoustical environments, and its long-throw bass driver allows for low-level distortion at high output levels. Large upfront panel ports reduce bass compression and make it easier to mount in tight spaces such as OB vans. Powerful analog amplifiers with large headroom offer an improved transient response and its wide range input gain and output level controls allow for easier interfacing with signal sources.  The KH 120 A also has 4-position bass, low-mid and treble acoustic controls for added comfort in diverse environments, and its one-piece front panel (with no discontinuities) offers reduced diffraction and a smoother frequency response. Separate woofer and tweeter peak limiters (and thermal-protection circuitry) provide high reliability. Wide horizontal and narrow vertical dispersion gives both freedom across the mixing console and reduced reflections of said console.

For production consistency, any KH 120 is "pair-matched" to any other KH 120 (ex: KH 120 A versus KH 120 D).

Neumann KH 805/KH 120 A Bundle Includes:

  • 1x KH 805
  • 3x Power cables (Euro, UK, USA)
  • 1x Operating manual
  • 1x Supplement “Getting Started Quickly”

Neumann KH805 Features:

  • Robust driver and cabinet
  • Sum output for multiple subwoofer systems (higher SPL, decreased distortion)
  • Four routing modes on right input connector
  • Planet Wave Bass Array™ (PWBA™) reduces lateral room modes
  • Extensive acoustic controls (output level, low cut, parametric EQ, 45°step phase control)
  • Switchable mains voltage
  • Input Ground lift
  • Remote-able electronics (REK 3) for installation convenience, less cabling
  • Low heat dissipation amplifier
  • Integrated limiter for amp and driver protection

Neumann KH 120 A Features:

  • Elliptical Mathematically Modelled Dispersion™ (MMD™) waveguide
  • Composite sandwich cone for damping of break-up modes
  • Long throw bass driver for low distortion at high sound levels
  • Robust metal grille
  • Large upfront panel ports
  • Compact aluminum cabinet minimizes resonances
  • Wide horizontal / narrow vertical dispersion
  • Powerful analog amplifiers with large headroom
  • 4-position bass, low-mid and treble acoustical controls
  • Wide range input gain and output level controls
  • Display dimmer for low lighting conditions
  • Ground lift: reduced noise in electrically noise environments, overcomes ground loops
  • Universal switch-mode power supply (100 - 240 V): one version works in any country
  • Separate woofer and tweeter electronic peak limiters and thermal-protection circuitry

Neumann KH805 Specifications:

  • ACOUSTICS
    • -3 dB free field frequency response: 18 - 300 Hz, ± 3 dB\
    • Pass band free field frequency response: 19 - 300 Hz, ± 2 dB
    • Self-generated noise  level at 10 cm: < 20 dB(A)
    • Total harmonic distortion < 0.5 % at 95 dB SPL at 1 m: > 40 Hz
    • Max. SPL In half space at 3% THD: 110.7 dB SPL
    • Max. SPL with pink noise In half space at 1 m: 112 dB SPL
    • Averaged between: 40 and 90 Hz
  • ELECTRONICS
    • Amplifier, cont. (peak) output power (THD < 0,1 %): 160 W (200 W)
    • Controller design: Analog, active
    • Main channel crossover frequency: 80 Hz
    • Crossover slope: 24 dB/oct
    • Equalization: Low cut: 30 Hz, 0 … -12 dB
    • Parametric Equalizer: Bypassable
    • Parametric Equalizer - Gain: +4 … -12 dB
    • Parametric Equalizer - Frequency: 20 … 120 Hz
    • Parametric Equalizer - Q: 1 … 8
    • Time of Flight adjustment delay: 0 … 4.69 ms @ 80 Hz (4-step 0, 45, 90, 135), - 180° Switch
    • Bass Management Remote Control: Bass management on/off; optional via a standard foot switch on a 6.3 mm jack
    • Protection circuitry: Peak and Thermo Limiters
    • Infrasonic filter frequency; slope: 6.5 Hz; 12 dB/oct.
    • Analog Inputs and Outputs:
      • Input/Output channels: 2.0 or 0.1 / 2 + Daisy Chain
      • Impedance electrically balanced: XLR, 13 kOhm
      • Input sensitivity: 94, 100, 108, 114 dB SPL at 1m for a 0 dBu input level
      • Max. input level: +24
      • Signal routing modes: Right, LFE 120 Hz, Wide, Daisychain
      • CMRR: > 56 dB @ 15 kHz
      • Interchannel isolation (1 kHz), level matching: -95 dB, ±0.1  dB
      • Dynamic range, THD+N: 119 dB(A), <0. 001% (-100 dB)
      • Gain Control: +2 … -12 dB
      • Displays and indicators:
        • power on: Green LED
        • limit/clip: Red LED “Flashing
        • bass management active: Green LED
      • Mains power: 220 - 240 / 100 - 120 V AC (switchable)
      • Power consumption - Idle: 14 W
      • Power consumption - Full output: 280 W
  • MECHANICS
    • Cabinet surface finish  Painted
    • Color: standard
    • Metallic Anthracite (RAL 7021)
    • Baffle cover: Metal grille (included)
    • Drivers: Magnetically shielded
    • Woofer: 265 mm (10")
    • Product dimensions (height x width x depth), mm (inches): 360 x 330 x 645 mm (14 1/8" x 13" x 25 3/8")
    • Net volume, internal / external: 41.5 l /76.6 liters
    • Product weight: 26 kg (57 lbs., 5 oz.)
    • Packed dimensions (height x width x depth), mm (inches): 515 x 490 x 750 mm (20 1/4" x 19 1/4" x 29 1/2")
    • Packed weight and cube: 32.0 kg (70 lbs., 9 oz.), 0.1893 m³

Neumann KH 120 A Specifications:

  • ACOUSTICS
    • -dB free field frequency response: 52 Hz to 21 kHz, ±3 dB
    • Pass band free field frequency response: 54 Hz to 20 kHz, ± 2 dB
    • Self-generated noise (with input gain set to 100 dB for 0 dBu): <20 dB (A) at 10 cm
    • Total harmonic distortion (<0.5% at 95 dB SPL at 1m): >100 Hz
    • Max. SPL in full space / calc. in half space at 3% THD at 1m: 104.8 dB SPL
    • Max. short term SPL with IEC-weighted noise at 1m: 107 dB(C) SPL
    • Max. short term SPL with music material at 2.3 m (pair): 97 dB(C) SPL [full range]; 104 dB(C) SPL [with subwoofer]
    • Max. long term SPL with pink noise at 2.3m: 88/93 dB(C) SPL [full range]; 89/94 dB(C) SPL [with subwoofer]
  • ELECTRONICS
    • Woofer amplifier, continuous (peak) output power: 50 W (80 W), THD and noise <0.1% with deactivated limiter
    • Tweeter amplifier, continuous (peak) output power: 50 W (80 W), THD and noise <0.1% with deactivated limiter
    • Controller design: analog, active
    • ACOUSTIC CONTROLS switches:
      • BASS: 0, -2.5, -5, 7.5dB
      • LOW-MID: 0, -1.5, -3, 4.5 dB
      • TREBLE: +1, 0, -1, -2dB
    • Protection circuitry: Limiter: low, high
    • Infrasonic filter frequency / slope: 30 Hz; 6 dB/oct.
  • ANALOG INPUT
    • Input type: XLR, electronically balanced
    • Input impedance:
      • 114 dB SPL: 20 kOhm
      • 108 dB SPL: 10 kOhm
      • 100 dB SPL: 20 kOhm
      • 94 dB SPL: 10 kOhm
    • Input gain control (sensitivity): 0 dB to -15 dB
    • OUTPUT LEVEL switch: 94, 100, 108, 114 dB SPL
    • CMRR:
      • >56 dB, 100 Hz to 10 kHz (ANALOG mode)
      • >56 dB, 100 Hz to 12 kHz (ANALOG DELAYED mode)
    • Maximum input level:
      • 24 dBu (ANALOG mode)
      • 18 dBu (ANALOG DELAYED mode)
  • PRODUCT PROPERTIES
    • Power consumption (idle): 20 W
    • Power consumption (full output AC): 200 W
    • Dimensions (HxWxD): 277 x 182 x 220 mm (10-7/8" x 7-1/8" x 8-5/8")
    • Internal net volume/external volume: 6.5 I/9.7 I
    • Weight: 6.4 kg (14 lbs., 2 oz.)
    • Drivers - woofer, tweeter: magnetically shielded - 130 mm (5.25"), 25 mm (1")
    • Threaded inserts for Neumann mounting hardware: 2 x M8 on rear panel with depth 15 mm (5/8")
    • Cabinet surface finish (Color): Painted aluminum; Anthracite (RAL 7021) or White (9016) or other RAL color
  • OPERATING CONDITIONS
    • Ambient temperature: +10 °C to +40 °C (+50 °F to +104 °F)
    • Relative humidity: max. 90 % (non-condensing)
    • Power supply: 100 to 240V-, 50/60 Hz
  • TRANSPORT/STORAGE CONDITIONS
    • Ambient temperature: -25 °C to +70 °C (-13 °F to +158 °F)
    • Relative humidity: max. 90%
