Neutrik NC3MDM3-V
Connector, DM3 Series 3-Pin M - PCBV w/M3 Mount Hole

OUR PART #:  NC3MDM3-V

Neutrik NC3MDM3-V is 3 pole male receptacle, vertical PCB mount with nickel housing, silver contacts and M3 mounting holes.
Learn More
Our Price: $3.92
List Price: $5.00
Save up to 34% when you order by quantity!
  • Buy 25: $3.54 each.
  • Buy 50: $3.42 each.
  • Buy 100: $3.29 each.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Neutrik NC3MDM3-V
Qty:
Similar Products

Neutrik NC3MDM3-V is 3 pole male receptacle, vertical PCB mount with nickel housing, silver contacts and M3 mounting holes.

Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling. UL recognized component.

Neutrik NC3MDM3-V Features:

  • D-shape metal shell
  • Optimal RF protection using 3 shield contacts
  • Insert is removable from rear of connector and locked into place by internal latch - permitting assembling and testing of pcb before assembling into housing
  • Front or rear panel mount

Neutrik NC3MDM3-V Specifications:

  • Product:
    • Connection Type: XLR
    • Gender: Male
  • Electrical:
    • Capacitance between contacts: = 4 pF
    • Contact resistance: = 5 m-Ohm
    • Dielectric strength: 1,5 kVdc
    • Insulation resistance: > 10 GOhm (initial)
    • Rated current per contact: 6 A
    • Rated voltage: < 50 V
  • Mechanical:
    • Insertion force: = 20 N
    • Withdrawal force: = 20 N
    • Lifetime: > 1,000 mating cycles
    • Wiring: Vertical PCB mount
    • Locking device: Latch lock
    • Mounting direction: Rear
    • Chassis shape: D
    • Mounting: Mounting holes with M3 threads
  • Material:
    • Contact plating: 2 µm Ag over 2 µm Ni
    • Contacts: Brass (CuZn35Pb2)
    • Insert: Polyamide (PA 6.6 30 % GR)
    • Locking element: Steel Ck67
    • Shell: Zinc diecast (ZnAl4Cu1)
    • Shell plating: Nickel
  • Environmental:
    • Approvals: UL
    • Flammability: UL 94 HB
    • Standard compliance: IEC 61076-2-103
    • Protection class: IP 40
    • Solderability: Complies with IEC 68-2-20
    • Temperature range: -30 °C to +80 °C
