ETC Desire D40 Studio Daylight 40x 5600K LED Par with Twistlock Cable, White

The SELD40DI-1-C from ETC is from their Desire Series of LED fixtures with this model being a D40 Studio Daylight version in white with a 20A twistlock connector. The D40 Studio Daylight – contains forty 5600K LEDs for high-intensity, non-variable cool-white output. ETC’s Selador® Desire D40 Studio lighting fixtures use the newest technology in high-output white-light LEDs to create an ideal luminaire for video, film and other ‘white light only’ applications.

ETC SELD40DI-1-C Includes:

• Hanging Yoke
• Very Narrow Secondary Lens
• Media Holder
• UL1573 PowerCon power input cable (This model comes with a 20A twistlock connector.)
• NOTE: C-Clamps are not included.

ETC SELD40DI-1-C Specifications:

• General:
  • 40-LED variable white-light wash fixture
  • ETL listed to UL1573 – the standard for stage and studio lighting units
  • IP20-rated for indoor use
  • Power and DmX in/thru connections for easy setup
  • User-friendly control interface with multiple modes and fixture settings
• Physical:
  • Rugged die-cast all-metal housing
  • Easy access slots for secondary lenses and standard 7.5” PAR accessories
  • Available in black (standard), white or silver (optional) or custom colors (contact your sales representative)
  • Hanging yoke standard. Optional yoke/floor stand available
• Electrical:
  • 100VaC to 240VaC 50/60 Hz universal power input
  • Neutrik power in and thru connections
  • Up to 10 fixtures (15A max) may be linked via power thru connector
  • Requires power from a non-dim source
• Inrush:
  • 120V / 15a
  • 240V / 40a
• LED*:
  • 50,000-hour LED life (50,000 hours to 70% intensity)
  • 40 Luxeon® Rebel LED emitters
  • Studio Daylight and Studio Tungsten use rebel ES white light emitters for higher output
• Optical:
  • Primary field angle of 17°
  • Secondary lenses available for multiple beam spread options
  • Fixtures ship with a Very narrow lens; additional lenses must be ordered separately
• Control:
  • DMX512 in and thru via five-pin XLR connectors
  • Multiple control options including strobe and console-free Primary/Secondary mode
  • 15-bit virtual dimming engine provides smooth, high-quality theatrical fades
  • RDM functionality for address and setting changes
• Thermal:
  • Ambient operating temperature of -4° to 104°f (-20° to 40°C)
  • Active electronic thermal management for droop-free operation
  • Noiseless, fan-free convection cooling for acoustically sensitive installations
  • Fixture is designed for continuous operation up to 104°F (40°C) ambient temperature and requires free flow of air around fixture housing

Note:

Actual product is WHITE in appearance.

All LED sources experience some lessening of light output and some colorshift over time. leD output will vary with thermal conditions. Thermal conditions can be affected by ambient temperatures and orientation. See theD40 ambient temperature and power Budgeting Guide for more details. Based on the LED manufacturer’s B50 l70 specification, a Selador luminaire will achieve~70% of its initial output after 50,000 hours of typical usage. In individual situations, LEDs will be used for different durations and at different levels.This can eventually lead to minor alterations in color performance,necessitating slight adjustments to presets, cues or programs.
