Chroma-Q CHCONEW100RGBA
Color One 100 RGBA LED Par in White

OUR PART #:  CHCONEW100RGBA

The CHCONEW100RGBA from Chroma-Q® is a Color One 100™ LED Par (IP20 rated) that  features an innovative fully homogenised beam...
Learn More
Our Price: $737.10
List Price: $780.00
You save 6%!

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Chroma-Q CHCONEW100RGBA
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The CHCONEW100RGBA from Chroma-Q® is a Color One 100™ LED Par (IP20 rated) that  features an innovative fully homogenised beam, virtually eliminating the color separation and shadows synonymous with LED lighting - delivering above Par performance from ONE source. This model also offers PowerCon and XLR-5pin In/Out. Utilizing core LED technology from the Chroma-Q premium performance lighting range, this multi-purpose fixture is ideal for a wide range of applications and provides a powerful, creative lighting tool.

NOTE: Actual product is WHITE in appearance.

Chroma-Q CHCONEW100RGBA Includes:

  • Wireless IR Remote
  • Color Frame

Chroma-Q CHCONEW100RGBA Features:

  • Fully homogenized beam
  • RGBA color-mixing palette
  • Extremely uniform wash
  • Defined 20° beam
  • Bold saturates and subtle pastels from ONE source
  • High CRI of 93
  • Floor, truss or wall mountable
  • Convection cooled for near-silent running
  • Theatrical grade dimming
  • Choice of IP20 and IP65 versions

Chroma-Q CHCONEW100RGBA Specifications:

  • Product Code: CHCONEW100RGBA (IP20)
  • Net Dimensions:
    • (Full Open Yoke): 8.5" x10.5" x 9" (214mm x 267mm x 232mm)
  • New Weight: 8.5lb (3.8kg)
  • Shipping Dimensions: 16" x 9"x 11.5" (406mm x 228mm x 292mm)
  • Shipping Weight: 12lb (5.5kg)
  • Power Supply: Built-in
  • Power Input Rating: 100-240V AC 50-60Hz 125VA
  • Power Factor: 0.5
  • Power Consumption: 52W (Maximum); 5.5W (Stand-by)
  • Typical Power & Current: Measurements done with all LEDs at maximum intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
  • Power Connectors In/Out: powerCON
  • Data Connectors In/Out: XLR 5-pin
  • Control Protocol: ANSI E1.11 USITT DMX 512-A
  • Cooling System: Convection
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Construction: Cast machined aluminium
  • Color: Black (custom colors available on request)
  • Built-In Hardware: Split Yoke, 6.25" Accessory Holder
  • Approvals: CISPR 15 / EN55015 & EN61547, FCC Part 15 Subpart B:2012 /ICES-003:2012, CSA C22.2, UL 1573, IEC 60598

Control & Photometric Data:

  • LED Engines: 1
  • LEDs Per Engine: 6 x RGBA
  • Total LEDs: 24
  • Control Modes: 4 channels RGBA, 5 channels RGBAI, 4 channels HSI, 3 channels RGB, 3 channels MLED RGB, Master, Slave
  • Dimming Curve: Theatrical
  • Variable Effects Engine: Yes (via Wireless IR Remote)
  • Effects Parameters: Flash, strobe, fade, smooth (via Wireless IR Remote)
  • Hot Lumen Output (Combined): 1,230
  • Optics: Fully homogenised
  • Beam Angle: 20°
  • Beam Distribution: Symmetrical direct illumination
  • CCT: Adjustable 1,000 - 10,000K
  • Color Gamut: Performance enhanced
  • CRI: 93
  • Lamp Life: L70 at 50,000 hours
