ETC/Elec Theatre Controls 4M50L-I-1
Source Four Mini LED, 50° Canopy Install with White Finish

OUR PART #:  4M50L-I-1

ETC's 4M50L-I-1 is a Source Four Mini LED light fixture that comes in white and with an install canopy mount. It features a 50° beam angle.
Learn More
Our Price: $434.00
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

ETC/Elec Theatre Controls 4M50L-I-1
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

ETC's 4M50L-I-1 is a Source Four Mini LED light fixture that comes in white and with an install canopy mount. It features a 50° beam angle.

ETC Source Four Mini LED Fixtures
Going where no full-sized Source Four® has gone before, the Source Four Mini LED features the same crisp optics, sleek look, and the same user-friendly functionality as the legendary Source Four fixture, but in a much more compact format at a fraction of the size. This particular Source Four Mini LED has (4) field-angle choices and comes in the canopy-mount design. Surprisingly bright for its size, the Mini LED offers crystal-clear image projection and a bright, even field.

Applications/Venues:

  • Museums
  • Retail stores
  • Restaurants
  • Lobbies
  • Light labs
  • Theaters

ETC 4M50L-I-1 Source Four Mini LED Features:

  • Rugged, die-cast fixture body with White Powder Coat Finish
  • Interchangeable lens tubes permit selection of 19°, 26°, 36°, and 50° field angles
    (Note: This model features the 50° version. Other options sold separately. Contact your Sales Pro for more information)
  • Uniquely efficient optical system
  • Long-life dimmable white LED source in two CRI values
    -- Source Four Mini LED: 80+ CRI
    -- Source Four Mini LED Gallery: 90+ CRI
  • Tool-free lamp replacement
  • Three-plane shutters
  • Multiple accessories available for color, pattern, and filtering
  • Insulated rear handle
  • Custom paint colors available; contact your Sales Pro for more information
  • Canopy-mount features:
    • Color-matched canopy
    • Canopy-mounting hardware for ceiling junction box included
    • 12V transformer or LED driver in canopy for hardwired 230V input

ETC 4M50L-I-1 Source Four Mini LED Specifications:

  • Physical:
    • Die-cast aluminum construction (A380 grade)
    • Fine-texture, high-temperature powder-coated paint
    • White Finish
    • Steel yoke with 0.406” diameter mounting hole
    • Rotating barrel: ±175°
    • E-size gobo pattern holder (included)
      -- 37.5mm with a 25.4mm image area
      -- Holds patterns up to .05" thick (1.27mm)
    • Stainless steel, full hard shutters in a tri-plane assembly, 0.40mm (A301 grade)
    • Fixed-beam angles to suit a range of throw distances
    • Tool-free tilt and beam adjustment
    • High-impact resistant, thermally insulated knobs and shutter handles
    • Captive accessory slot for pattern holder (included)
    • Dual captive accessory slots for media frame (included)
    • Install canopy -
      -- Color-matched, powder-coated canopy mount with LED driver (included)
      -- Canopy dimensions: 5.31" W x 1.04" H
      -- Installation hardware included
      -- Fixture to canopy factory pre-wired for easy install
      -- Built-in rotation stop to prevent cable damage
    • Black or white power lead
    • IP20  Rated
  • Electrical:
    • Power at full intensity: 12W typical, 14W max
    • 18 AWG input wire size
    • Input voltage options:
      -- 90-135V, 50/60Hz
      -- 190-250V, 50/60Hz
    • Dimmable (forward and reverse phase)
    • Inrush (first half-cycle)
      -- 120V: <1A
      -- 240V: <1A
  • Lamp:
    • Cree LED (Available in 80+ and 90+ CRI)
    • Long-life lamp: 35,000 hours, L70 lumen maintenance
    • 3000K color temperature
  • Optical:
    • Fixed-beam options of 19°, 26°, 36°, and 50° field angles
      (Note: This model features the 50° version. Other options sold separately. Contact your Sales Pro for more information)
    • Projector-quality, high-contrast lenses
    • Beam edge continually adjustable hard to soft
  • Thermal:
    • 0° C to +40° C
  • Approvals:
    • ETL listed to the following standards: UL/cUL1598
