Community IS6-215W
I Series Dual 15" 1400W (4 Ohms) Medium Power Passive Installation Subwoofer in White

OUR PART #:  IS6-215W

The Community IS6-215W is an I Series Subwoofer 600 dual 15" 1400W (4 Ohms) passive installation subwoofer in white.
Learn More
Our Price: $2,165.00

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Community IS6-215W
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The Community IS6-215W is an I Series Subwoofer 600 dual 15" 1400W (4 Ohms) passive installation subwoofer in white. It's well-suited for many applications, such as houses of worship, auditoriums, restaurants, meeting rooms, corporate A/V systems, arenas, stadiums, or any other use where extended low-frequency reinforcement is needed.

I Series Subwoofer 600 loudspeakers give excellent acoustic performance, modular flexibility, plus elegant aesthetics for modern performance venues. Designed to support the goals of systems integrators and consultants both acoustically and mechanically, I Series Subwoofers provide a broad assortment of sizes and capabilities that can be specifically matched to the needs of any contemporary venue.

Each cabinet was carefully designed to provide matching heights, face widths, as well as suspension point locations for seamless integration into flown arrays with I Series full-range models. The broad range of optional low profile fly rails, fly frames and modular array brackets reduces design and installation time while also providing improved aesthetics and nearly limitless integration possibilities.

A compact, direct radiating subwoofer, the IS6-215W has large, balanced ports that provide optimal enclosure tuning and even air pressure distribution to the driver ones, reducing distortion and extending system longevity. Drivers are loaded into individual air volumes within the enclosure, isolating their performance from one another. This arrangement not only provides additional protection to drivers in case of failures, but also allows the designer to implement directional subwoofer techniques, like steered end-fire arrays and cardioid patterns, within a single enclosure when using any I Series dual driver subwoofer model.

Applications Include:

  • Small to Medium Size Venues:
    • Houses of Worship
    • Auditoriums
    • Restaurants
    • Meeting Rooms
    • Theaters
    • Corporate A/V Systems
  • Larger Size Venues:
    • Arenas
    • Stadiums
    • Night Clubs
    • Theaters
    • Themed Entertainment
    • Larger Houses of Worship

Community IS6-215W Features:

  • Long excursion ferrite LF drivers with FEA-optimized motors and symmetric movement suspension
  • Matched-size enclosure and aligned suspension point for seamless flown array integration
  • 1400W continuous power handling (5600W peak)
  • High sensitivity design minimizes power compression losses and required amplifier size
  • Isolated driver air volumes allow use of directional steering techniques within a single enclosure

Community IS6-215W Specifications:

  • Operating Mode: Single or Dual Amp
  • Operating Environment: Indoor
  • Operating Range: 37 Hz - 145 Hz
  • Transducers: 2x 15" (381 mm) double-treated cones with 4" (102 mm) inner/outer wound voice coil, ferrite construction
  • Continuous Power Handling @ Nominal Impedance:
    • Single Amp, 75V: 1400W @ 4 Ohms (5600W peak)
    • Dual Amp, 75V: 700W @ 8 Ohms (2800W peak) each
  • Nominal Sensitivity:
    • Half Space: 105dB @ 1W; 108dB @ 2.83V
    • Whole Space: 99dB @ 1W; 102dB @ 2.83V
  • Nominal Maximum SPL:
    • Half Space: 136dB continuous; 142dB peak
    • Whole Space: 130dB continuous; 136dB peak
  • Equalized Sensitivity:
    • Half Space: 102dB @ 1W; 105dB @ 2.83V
    • Whole Space: 96dB @ 1W; 99dB @ 2.83V
  • Equalized Maximum SPL:
    • Half Space: 133dB continuous; 139dB peak
    • Whole Space: 127dB continuous; 133dB peak
  • Recommended Amplifiers:
    • Single Amp: 1400W - 2800W @ 4 Ohms (75V - 106V)
    • Dual Amp: 700W - 1400W @ 8 Ohms (75V - 106V) each driver
  • Physical:
    • Dimensions (HxWxD): 39.00" x 16.50" x 23.35" (991 x 419 x 593 mm)
    • Weight:
      • Product: 126 lbs (57.2 kg)
      • Shipping: 147 lbs (66.7 kg)
    • Finish: White low gloss, uniformly textured painted 15mm Baltic Birch plywood with powder-coated steel grille
    • Input Connection: (2) 4-position screw terminal blocks
    • Mounting Points: (24) M10 threaded rigging points
    • Environmental: IPX4 per IEC 60529, designed in accordance wtih MIL-STD-810G
