Turbosound NuQ-15WH 15" 2-Way 600W (8 Ohms) Passive Full-Range Loudspeaker in White

OUR PART #: NUQ-15WH

Copied to clipboard
Turbosound NuQ-15WH 15" 2-Way 600W (8 Ohms) Passive Full-Range Loudspeaker In White Image 1
Turbosound NuQ-15WH 15" 2-Way 600W (8 Ohms) Passive Full-Range Loudspeaker In White Image 2
Turbosound NuQ-15WH 15" 2-Way 600W (8 Ohms) Passive Full-Range Loudspeaker In White
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Product Overview

The Turbosound NuQ-15WH is a switchable active/passive full range two-way loudspeaker system designed to be used with Turbosound LMS series digital loudspeaker management systems, providing optimum system performance. NuQ systems can be controlled over a BVNet network using TurboDrive control software.

This speaker consists of a front loaded 15" neodymium LF driver and a 1.4" neodymium HF compression driver on a rotatable 80°H x 50°V Converging Elliptical Waveguide, matched with an internal passive crossover network in a reflex-loaded enclosure, giving excellent pattern control and allowing a swap of horizontal and vertical coverage patterns. The symmetrical shape creates an additional role as mirrored left/right monitor wedges. Bi-amp mode can be enabled by means of a rear panel switch. The trapezoidal enclosure is uniquely formed out of pre-bent plywood, which entirely eliminates four cabinet joints and provides additional benefits of superior strength, low weight and reduced internal reflections.

The cabinet includes a steel mesh grille backed with reticulated foam, and is finished in black or optional white textured paint and includes rigging points for use with optional flying yokes and wall brackets, as well as being compatible with OmniMount loudspeaker brackets. A pole mount socket is fitted for use with 35mm poles and speaker stands. The rear panel connector plate carries two Neutrik speakON NL4 connectors for loop in and loop out connections to additional enclosures.

Turbosound NuQ-15WH Features:

  • 2 way full range loudspeaker for portable PA applications
  • 600 Watts continuous, 2,400 Watts peak power
  • Ideal for FOH, side fill and monitor applications
  • 15” neodymium low frequency driver
  • 1.4” neodymium HF compression driver
  • Rotatable converging elliptical waveguide provides 80° H x 50° V dispersion
  • 15 mm (5/8”) birch plywood enclosure with hard wearing semi matte white paint finish
  • Rugged powder coated perforated steel mesh grille
  • Integral 35 mm pole mount and handles
  • M10 and M8 rigging points compatible with Turbosound and OmniMount brackets
  • Neutrik speakON NL4 connectors for reliable long life operation
  • 3-Year Warranty Program
  • Designed and engineered in England

Turbosound NuQ-15WH Specifications:

  • Components: 1 x 15" (381 mm) LF Driver, 1 x1.4" (35 mm) HF Driver on a Converging Elliptical Waveguide
  • Frequency Response: 50 Hz - 20 kHz ±3 dB; 45 Hz- 20 kHz ±10 dB
  • Dispersion: 80° H x 50°V @ -6 dB points. Rotatable Waveguide Allows Swap of Horizontal and Vertical Pattern
  • Sensitivity (1 W @ 1 M): 100 dB
  • Power Handling: LF: 500 Watts Continuous, 1,000Watts Peak; HF: 100 Watts Continuous, 400 Watts Peak; Passive: 600 Watts Continuous, 2,400 Watts Peak
  • Calculated Max SPL: 129 dB Continuous, 135 dB Peak
  • Nominal Impedance: LF: 8 Ohms, HF: 6 Ohms, Passive: 8 Ohms
  • Crossover: Internal Passive Crossover at 1.6kHz, 24 dB/Octave Butterworth
  • Construction: 15 mm (5/8") Birch Plywood, Finished in Semi Matte White Paint
  • Grille: Powder Coated Perforated Steel with Acoustically Transparent Reticulated Foam
  • Connectors: 2x Neutrik speakON NL4, wired Pin1+: Positive, Pin 1-: Negative, Pins 2+ and 2-: N/C
  • Rigging:
    • M8 Rigging Points for WB-55B Wall Brackets
    • M6 Rigging Points for OmniMount Brackets
    • M10 Rigging Points for Flying Yokes and Eyebolts
  • Dimensions (HxWxD): 28" x 16.9" x 15.2" (712mm x 430mm x 385mm)
  • Net Weight: 57.2 lbs (26 kg)

NOTE:

Images shown above are for illustrative purposes only; actual product will come White in color. For more information on this and other products, contact your Sales Representative.
