Galaxy Audio AXS-8
8 Channel Mixer with 4 Microphone Inputs

OUR PART #:  AXS-8

The Galaxy Audio AXS-8 analog audio mixers has a USB connection to link to a computer for stereo playback or recording and +48V phantom power to the XLR inputs.
Learn More
Galaxy Audio AXS-8 - Side View
Galaxy Audio AXS-8 - Side View
Galaxy Audio AXS-8 - Top View

Click a thumbnail to see more images. (6 total)

Our Price: $249.99
List Price: $399.99
You save 38%!
Be the first to review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Galaxy Audio AXS-8
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The Galaxy Audio AXS-8 analog audio mixers has a USB connection to link to a computer for stereo playback or recording and +48V phantom power to the XLR inputs. Additionally, all mono inputs provide an easy-to-use single knob compression. The AXS-8 also features a 3-band EQ with sweep-able mid-range and low cut filter, as well as AUX sends on each channel, which are either pre/post or switchable for monitoring/FX or external send.

The AXS-8 has built-in Studio Grade DSP FX with 16 effects. Effects include Reverb, Chorus, Flanger, Delay, Pitch Shifter, and Multi-Effects. Each effect has a storable user parameter and a tap button with a tempo light that provides for delay and echo settings.

Each channel also provides the user with Clip LEDs, Mute, Subgroup Routing, Solo, L/R Panning and PFL. The mono channels also feature 1/4" TRS inserts for flexible connection to outboard effects and processing. Whether using in a fixed install or on the road, the 60mm logarithmic faders and sealed rotary controls will provide clean, reliable sound.

Galaxy Audio AXS-8 8-Channel Mixer Features:

  • 8 Input, 4 XLR Mic Input & 2 Stereo Inputs
  • 4 +48V Phantom Powered Mic Preamps
  • 4 Easy to use Built in Compressors
  • 3-Band EQ on Each Channel
  • 16 Effects with Tap
  • USB Audio Interface
  • 2 AUX Sends Per Channel
  • PFL on Each Channel
  • Balanced Main Outputs
  • Headphone Output
  • Control Room Controls
  • 60 mm Logarithmic Faders
  • Sealed Rotary Controls
  • Switching Power Supply

Galaxy Audio AXS-8 8-Channel Mixer Specifications:

  • Max. Input Level: Mic +22dBu, Other Line +20dBu
  • Max. Output Level: Main XLR +28dBu, Other Output +22dBu
  • Meters: 3 Color LED
  • Sensitivity: 0VU=+4dBu
  • Master Meter: 12 Segment, -30dB to clip
  • Channel meter: Red LED, clip
  • Frequency Response: +/- 1dB, 20Hz - 30KHz
  • Mic CMRR at 1kHz: >70dB typical
  • THD+n at +14dBu at 1kHz: Mic to mix out <0.005%
  • Crosstalk (@1KHz): Fader shutoff >89dB, Mute shutoff >89dB
  • Noise, rms 20Hz to 20kHz: Mic Input E.I.N -129dBu
    • Main mix fader unity, Channel fader down <-95dBu(-97dB S/N)
    • Main mix fader unity, Channel fader unity <-82dBu(-86dB S/N)
  • Channel HPF: 18dB/oct below 75Hz
  • Mono EQ:
    • Lo: +/-15dB shelving at 80Hz
    • Mid: +/-15dB peak at 2.5kHz
    • Hi: +/-15dB shelving 12kHz
  • Stereo EQ:
    • Lo: +/-15dB shelving at 80Hz
    • Mid: +/-15dB peak at 2.5kHz
    • Hi: +/-15dB shelving at 12kHz
  • DSP: Converter 24-bit sigma-delt, 64/128-times oversampling, Sampling Rate 40kHz
  • USB: Audio Stereo In/Out, Connector Type B, Converter 16-bit, Sampling Rate 48kHz
  • Power Supply: 110-240VAC, 50/60kHz
  • Power Consumption: 40 watts
  • Fuse: 100-240VAC, T 1.6A, 250V, 5x20mm
  • Dimensions: 4.41" x 12.64" x 15.75" (112 x 321 x 400 mm)
  • Weight: 9.6 lbs (4.36 kg)
