Radial Engineering JDI Stereo 2-Channel Passive Direct Box

OUR PART #: JDI-STEREO MFR #: R800 1012

Copied to clipboard

The Radial JDI Stereo is considered by many to be the world’s finest stereo direct box. ...Read more

Radial Engineering JDI Stereo 2-Channel Passive Direct Box Image 1
Radial Engineering JDI Stereo 2-Channel Passive Direct Box Image 2
Radial Engineering JDI Stereo 2-Channel Passive Direct Box Image 3
Radial Engineering JDI Stereo 2-Channel Passive Direct Box Image 4
Radial Engineering JDI Stereo 2-Channel Passive Direct Box
Our Price: $379.99
List Price: $456.00
You save 17%!

SPECIAL FINANCING AVAILABLE

Synchrony Music & Sound Card
$11/mo* with 36 month financing. ‡
Limited Time. Learn How

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The Radial JDI Stereo is considered by many to be the world’s finest stereo direct box. It is a passive DI that employs a pair of Jensen isolation transformers for optimum audio performance offering outstanding linearity at all frequencies, combined with extraordinary level handling without introducing distortion. Being completely passive, the plug & play JDI Stereo does not require any powering and has the unique advantage of eliminating 60-cycle ground loops. This makes the JDI-Stereo a definite favorite with informed audio engineers. The JDI-Stereo is great for guitars, bass, and keyboards and is particularly adept with high-output, broadband instruments such as active instruments and digital keyboards. The JDI may be rack-mounted using the J-Rak and is also available in a stereo (2-channel) version called the JDI Duplex and the 6-channel rack-mountable JD6.

You expect only the best from your stage equipment, and your direct box is no different. Go with the industry standard JDI Stereo today and keep on making music for years to come.

Features

  • Jensen transformer-equipped passive DI
  • Eliminates hum and buzz from ground loops
  • Virtually zero phase and harmonic distortion
  • Exceptional signal handling and noise rejection
  • Pad for active instruments and high-output keyboards

Specifications

  • Audio circuit type: Passive, transformer based
    • Transformer: Jensen JT-DBE
  • # of Channels: Two channels (dual mono)
  • Frequency Response: 20 Hz to 20 kHz (±0.2 dB)
  • Dynamic Range: 135 dB
  • Total Harmonic Distortion: 0.05% from 20 Hz to 20 kHz @ -10 dB
  • Phase Deviation:
    • 0.3° @ 100 Hz
    • 3° @ 20 Hz
  • Input Connectors: 1/4" unbalanced
    • Input Impedance: 140 kΩ, unbalanced
    • Maximum Input: +21 dB @ 20 Hz to 20 kHz
  • Output Connectors: XLR out, 1/4" thru
    • Output Impedance: 150 Ω, balanced
  • Features: Input pad, ground lift
  • Construction: 14-gauge steel chassis and outer shell
  • Power: Passive, no power required
  • Conditions: For use in dry locations only, 5-40°C
  • Dimensions (H x W x D): 1.8" x 3.3" x 5"
  • Weight: 1.55 lbs (703 g)
