Product Overview
The TOA AV-60S-AM introduces a new standard in small amps for plenum use. With ultra-compact size, a flexible complement of inputs & power configuration, control features and carrying both UL2043 & Energy Star 2.0 certification, the AV-60S-AM is an ideal choice for corporate meeting rooms, POS / signage & kiosks or any place where space and placement limitations are a factor.
Features:
- Micro Class D amplifier for use in meetings / boardrooms & signage applications
- UL 2043-rated for plenum installation
- Energy Star certified including Auto Off / Standby
- 60W x 2 @ 4Ω / 60W @ 70V
- Small size (approx. 6" x 6" x 1.75") allows convenient & flexible placement
- L / R Line inputs via removable Transformer-Balanced Terminal Block, 1/8" TRS mini-jack and RCA connections
- Bass & Treble Controls
- Input signal present (-20dB) and Peak LED indicators
- Clip Limiter prevents distortion due to overload.
- Remote Volume Control port for use with 10kΩ pot
Specifications:
- Power Supply: AC100V-240V, 50Hz / 60Hz; AC inlet on rear panel
- Efficiency: More than 70% at rated output in all Channels
- Power Consumption:
- Less than 1W in power save mode
- Less than 10W @ 70V idle
- Less than 7W @ 4Ω idle
- Less than 85W @ 70V rated output
- Less than 110W @ 4Ω rated output
- Output: 60W @ 4Ω; 60W @ 70V
- Power Amplifier Type: Class D
- Standards:
- UL2043 2008 Version, cULus Standard UL60065 7th Edition & CSA C22.2 NO.1-98,
- Energy Star Version 2.0 Audio / Video specification, and FCC part 15 class B
- Protection:
- Thermal protection
- Over current protection
- Input:
- Line 1: -10dB / -20dB (selectable), 10kΩ, transformer balanced, removable terminal block (3-Pin) x2
- Line 2: -10dBV / -20dBV (selectable), 10kΩ unbalanced, 3.5mm mini phone jack
- Line 3: -10dBV / -20dBV (selectable), 10kΩ unbalanced, RCA pin jacks
- Indication:
- Power LED (green) (front panel)
- Signal LED (green) (front panel)
- Peak LED (red) (front panel)
- Protect LED (yellow) (front panel)
- Ventilation: Normal air ventilation Fin or Mesh to apply for UL2043
- Frequency Response:
- 4Ω Mode: 20Hz - 20kHz ±3dB
- 70V Mode: 60Hz - 20kHz ±3dB < /UL>
- THD+N: Less than 0.15% @ 1kHz, xW (with best THD)
- Temperature Range (Operation): -10°C to +40°C
- Dimension: 150mm L x 45mm H x 150mm D (H should fit for EIA Rack)
- Case: Black metal case
