Osprey Video 260e
PCIe Analog Video Capture Card Stereo Audio with SimulStream

OUR PART #  95-00474

Our Price: $766.00
Usually ships in 7-14 business days.
Need it sooner? Call us!

The Osprey 260e video capture card is a single-channel card that supports composite, component, and S-Video inputs along with balanced or unbalanced stereo audio.

Single Channel With Switchable Inputs:

  • 1 composite (BNC x1)
  • 1 S-Video (mini-DIN)
  • 1 component (BNC x3)

Audio Inputs:

  • Balanced stereo (XLR x2)
  • Unbalanced stereo (RCA x2)

Audio Loop out: Stereo (3.5 mm)

Multiple Card Support: Deploy two or more cards in a single PC chassis for maximum versatility.

Driver Support:

  • Microsoft® DirectShow® drivers are available for compatibility with most software.
  • Open source Linux V4L drivers available.
  • Microsoft Windows lets you create custom applications.

Driver Based Pre-Processing*:

  • Closed-caption extraction/rendering
  • Logo/bitmap overlay
  • Scaling, cropping, de-interlacing and inverse telecine
    *WindowsDirectShow only

Osprey SimulStream® Ready

SimulStream is an optional Osprey feature which allows each input to produce multiple parallel output streams with completely independent settings for color space, cropping, scaling, closed caption and overlays facilitating simultaneous delivery to multiple applications.

Includes:

  • Y/C to S-Video adapter
  • Breakout cable
  • Low-profile bracket

Osprey 260e Specifications:

  • Description: Single channel analog
  • Format:
    • PCIe (x1):
      Slots: x1, x4, x8, or x16
      PCIe 1.1
  • Video Input:
    • Composite
    • Component
    • S-Video
  • Video Connector:
    • Composite (BNC x1):
    • Y/C (BNC x2) (BNC to mini-DIN adapter included)
    • Component (BNC x3)
  • Video Modes:
    • NTSC/PAL
    • 720 x 480 29.97, 30/i (NTSC)
    • 852 x 480, 29.97, 30/i (NTSC Wide Screen)
    • 720 x 576 25/i (PAL)
    • Wide Screen Signaling (WSS)
  • Audio Input: Unbalanced stereo (RCA x 2)
  • Audio Output: Unbalanced stereo line (3.5 mm)
  • Audio Connector:
    • Unbalanced stereo (RCA x 2)
    • Unbalanced (3.5 mini phono) stereo
  • Dimensions: 5" L x 2.71" H (12.70 x 6.88 cm)
    Low profile/half length
  • Weight: approx. 65 g
  • Power Consumption: 3.58 W
  • Operating Temp Range: 0° to 40° C
  • Non-Operating Temp Range: -40° to +75° C
  • Relative Humidity:
    • Operating: Between 5 % and 80 % (noncondensing)
    • Non-Operating: 95 % RH (non-condensing); gradient 30% per hour
  • Altitude Range:
    • Operating: 0 to 3,048 meters (10,000 feet)
    • Non-Operating: 0 to 15,240 meters (50,000 feet)
  • Warranty: 1 year limited hardware warranty
