Palmer PGA04L16
16Ohm Loadbox with Speaker Simulator


The Palmer PGA04L16 is a Special DI box with loadbox for guitars.
Learn More
Our Price: $679.95
List Price: $1,121.95
You save 39%!
Write the first review.
Palmer PGA04L16
Usually ships in 7-14 business days.
Need it sooner? Call us!

Related Products

The Palmer PGA04L16 is a Special DI box with loadbox for guitars. The integrated load resistor permits tube amplifiers up to approximately 120 W to be connected to the PGA04, bypassing a loudspeaker. A jack socket (unbalanced) and balanced XLR connector are available for direct pickup of the signal. The extensive filter section provides for a realistic simulation of classic guitar loudspeaker sounds.

Palmer PGA04L16 Specifications:

  • Product type: Speaker simulator
  • Type: Passive
  • Channels: 1
  • Input type: Unbalanced
  • Inputs: 1
  • Input connectors: 6.3 mm Jack
  • Output type: Unbalanced, balanced
  • Outputs: 2
  • Output connectors: XLR, 6.3 mm Jack
  • Output impedance: 600 (XLR), 10 k (6.3 mm Jack)Ohm(s)
  • Controls: high, low, color, filter volume, full range volume, high cut
  • Display: Max. load
  • Dummy load: Yes
  • Dummy load impedance: 16 Ohm(s)
  • Max. load: 100 W
  • Voicing filter: Yes
  • Power attenuator: No
  • Transformer balanced inputs: No
  • Transformer isolated outputs: Yes
  • Cabinet material: Sheet steel
  • Cabinet surface: Powder coated
  • Dimensions (WxDxH) 480 x 180 x 44.5 mm (1 U)
  • Weight: 2.56 kg
