Panasonic 55LFV52X2VW
2x2 Video Wall Bundle with TH-55LFV5U Displays


Call for price! Not available online.
List Price: $24,637.00

The Panasoni 55LFV52X2VW is a 2x2 video wall bundle with their TH-55LFV5U 55" Super Narrow Bezel LED displays. This narrow bezel is optimal for multi-screen layouts and for display with high visibility. The Multi-Display function enlarges images both vertically and horizontally by the same zoom ratio in both vertical and horizontal directions, or by different ratios in order to effectively use vertically or horizontally elongated spaces. Display versatility can be further enhanced by freely selecting the zoom ratio to match the installation space.

This unit suppresses ambient light reflection and reduces glare to make text and information easy to see. This model also allows you to choose the video wall size to match your installation condition with the 2x2 configuration of four LED displays giving you a 110" diagonal screen size. And, the super narrow bezel reduces the joint width when installed in a video wall configuration, providing a nearly seamless display.

These factors make this bundle an ideal option for use in multi-screen digital signage applications, rentals and staging, meeting rooms, broadcast studios and control rooms for traffic or logistics management where highly detailed information is displayed.

The TH-55LFV5U from Panasonic is an ultra-narrow bezel 500cd/m2 brightness LED display designed for large digital signage and command & control video walls. With the slimmest bezel width of approximately 3mm, TH-55LFV5Us can be combined to create near seamless large video wall displays. With features like IR Throughput, DVI-D In/Out and RS-232C In/out, and the ability to produce uniform brightness across multiple display solutions, the TH-55LFV5U is easily integrated into impressive video walls.

The TH-55LFV5U also has a Direct LED backlight and IPD LCD panel for bright efficient signage and video with wide viewing angle. VESA 400 x400mm Compatibility along with the ability to be displayed in both portrait and landscape orientation give the mounting flexibility to support nearly any video wall configuration.

NOTE: Product shown in image is for illustrative purposes only. Actual product may vary in appearance.


  • 4x TH-55LFV5U 55" Narrow Bezel LED Displays
  • TY-CF55VW5 Frame Cover Kit for 55LFV5 Video Wall
  • TY-RM50VW IR Remote Control Kit

Panasonic TH-55LFV5U Features:

  • Direct-lit LED Backlight Used
  • High Reliability Enables Continuous 24-Hour Operation
  • Support to Installation in a Multi-Screen System
  • Suppresses ambient light reflection and reduces glare for high visibility

Panasonic TH-55LFV5U Specifications:

  • Model: TH-55LFV5U
  • Display:
    • Screen Size: 54.6" (1,387.8 mm)
    • Panel: DIRECT LED
    • Resolution (HxV): 1920 x 1080 pixels
    • Brightness: 500 cd/m2
    • Viewing Angle: 178 degrees
  • ConnectionTerminal:
    • Video In: BNC x1
    • Audio In (L/R): RCA x1 set
  • Component RGB/In: 1 set (BNC x3)
    • HDMI In: HDMI x1
    • DVI-D IN/Out: 24-pin x1 / 24-pin x1
    • PC In: MINI D-SUB 15-PIN x1 (Female)
  • Audio In: M3 jack x1
  • Speaker Out: External Speaker Terminal (Side), 20W (10W x 10W)
  • Line Out: RCA Pin (L/R) x1 (Side)
  • Control Terminal:
    • LAN: RJ45 x1 (Web Browser Control)
    • Serial Port: D-SUB 9-pin x1 (SERIAL IN/Out) RS-232C Compatible
    • IR IN/OUT: IR x1 / x1
  • Electrical:
    • Power Requirements: 110-127 V AC, 50Hz/60Hz, 120 V AC 50/60HZ, 220-240 V AC, 50/60Hz
    • Power Consumption: 220W
  • Mechanical:
    • Display only: 47.85" W x 27.02" H x 4.77" D (1,215.5 x 686.3 x 121.2 mm)
    • Carton Dimensions: 61.07" W x 38.55" H x 17.72" D (1,551 x 979 x 450 mm)
    • Weight: approx. 79.3 lbs (36 kg)
    • Gross weight: approx. 114.7 lbs (52 kg)
    • Cabinet Color: Metal / Black
  • OperationEnvironment:
    • Temperature: 32°F to 104°F (0 to 40 degrees C)
    • Humidity (Non-condensation): 10% to 90% (Non-condensation)
  • Included Accessories:
    • AC Cord
    • Operating Instructions Book
    • DVI Cable
    • Wire Clampers

NOTES on Video Wall Bundles:

  • A mounting bracket compliant with VESA standard isrequired for wall mounting.
  • Some degradation occurs when images are enlarged.
  • Provide an appropriate air-conditioned environment because the ambient temperature varies depending on the installation condition and location.
  • Panasonic Video Wall Bundle Ships Direct From Panasonic Only.

NOTE: Additional information and specification materials available for review in Documentation tab.
