Liberty AV Solutions DL-HDV
HDMI to VGA Converter

OUR PART #:  DL-HDV

The Liberty AV Solutions DigitaLinx DL-HDV is an HDMI to VGA converter designed to connect digital video sources to an analog display or projector.
Learn More
Our Price: $44.96
List Price: $49.95
You save 10%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Liberty AV Solutions DL-HDV
Qty:

Similar Products

The Liberty AV Solutions DigitaLinx DL-HDV is an HDMI to VGA converter designed to connect digital video sources to an analog display or projector.

The DL-HDV supports HDTV video resolutions up to 1080p and VESA video resolutions up to 1920x1200. Only non-encrypted signals will be converted and passed through the device to comply with HDCP specifications. Power for the converter is supplied by the VGA display; a secondary power supply is not required.

The small form factor and lack of external power sources make the DL-HDV an ideal accessory to carry with every mobile device with an HDMI output to prevent any issues connecting to legacy video systems.

Applications

  • Adapt older displays to new sources
  • Handy for presenters to keep in laptop bag

Liberty AV Solutions DL-HDV Features and Benefits:

  • Extremely small size; durable metal housing
  • Maintains native resolution and aspect ratios
  • Supports signals up to 1080p and 1920x1200
  • No power required (powered from VGA 5v)
  • No audio support
  • Only non-encrypted signals will be converted

Liberty AV Solutions DL-HDV Technical Specifications:

I/O Connections

  • HDMI Input:  One (1) HDMI Type A Receptacle Connector
  • VGA Output:  One (1) Female HD15 Connector

Supported Video

  • HDTV Video Resolutions:  720p (1280x720), 1080p (1920x1080)
  • VESA Video Resolutions:  800x600, 1024x768, 1152x864, 1280x768, 1280x800, 1280x960, 1280x1024, 1360x768, 1366x768, 1400x1050, 1440x900, 1600x900, 1680x1050, 1920x1200
  • Maximum HDMI Distance 3m (10ft)
  • Maximum VGA Distance:  3m (10 ft)

Chassis and Environmental

  • Enclosure:  Painted Zinc Alloy
  • Dimensions:  23 mm x 11.8 mm x 41.5 mm (0.90 in x 0.46 in x 1.63 in)
  • Shipping Weight:  57 g (0.126 lb)
  • Operating Temperature:  0° to +40° C (+32° to +104° F)
  • Operating Humidity:  20% to 90%, Non-condensing
  • Storage Temperature:  -10° to +60° C (+14° to +140° F)
  • Storage Humidity:  20% to 90%, Non-condensing

Power, ESD, and Regulatory

  • Power Source:  via 5V DC connection VGA device
  • Power Consumption:  5 watts (max)
  • ESD Protection:  ±8kV (air-gap discharge), ±4KV (contact discharge)
  • Regulatory:  FCC, CE, RoHS

Other

  • Warranty:  2 years
  • Included Accessories:  None
