Neutrik NADB15MF
15-Pin D-SUB Male to Female Feedthrough with Nickel Housing

OUR PART #:  NADB15MF

The Neutrik NADB15MF is a 15-pin D-SUB male to female feedthrough with a nickel D-shape housing.
Learn More
Sale Price: $19.72
List Price: $31.10
Save up to 39% when you order by quantity!
  • Buy 100: $19.00 each.
Write the first review.

Related Products

The Neutrik NADB15MF is a 15-pin D-SUB male to female feedthrough with a nickel D-shape housing. This feedthrough is ideal for audio networking and integration of equipment into video systems.

Neutrik NADB15MF Specifications:

  • Electrical:
    • Contact Resistance:  10 Megohms (inner)
    • Dielectric Strength:  1 kVdc
    • Insulation Resistance:  >/= 5 Gigohms
    • Number of Electronical Contacts:  15
    • Rated Current per Contact:  5 A
    • Rated Voltage:  125 V AC
  • Mechanical:
    • Wiring:  Feedthrough
    • Chassis Shape:  D
  • Material
    • Contact Plating:  Au
    • Contacts:  Brass (CuZn39Pb3)
    • Insert:  Steel , tin plated, PBT
    • Shell:  Zinc diecast (ZnAl4Cu1)
    • Shell Plating:  Nickel
  • Environmental:
    • Flammability:  UL 94 V-0
    • Temperature Range:  -25°C to +85°C
