West Penn AQ245-500
500' 16AWG Aquaseal WIre

OUR PART #:  AQ245-500

16/4 Stranded bare copper conductors, overall unshielded with Aquaseal tape and overall jacket.
Learn More
Our Price: $366.81
Write the first review.
West Penn AQ245-500
Usually ships in 7-14 business days.
Need it sooner? Call us!

Related Products

16/4 Stranded bare copper conductors, overall unshielded with Aquaseal tape and overall jacket. Materials suitable for outdoor use, and indoor trays, allows a variety of uses for (Low voltage industrial process control circuits, Power-Limited circuits, Power-Limited fire alarm circuits, Power-Limited tray cable PLTC).


  • Conductor: 16 AWG Bare Copper
  • Stranding: 7x24
  • Insulation Material: PVC with Nylon
  • Insulation Thickness: PVC 0.015'' Nom.
  • Nylon: .005” Nom.
  • Number of Conductors: 4
  • Shield: None
  • Drain: None
  • Water-Blocking Tape: 2 Ply water swellable tape
  • Jacket Material: Sunlight/ Moisture Resistant PVC
  • Jacket Thickness: 0.040'' Nom.
  • Overall Cable Diameter: 0.355'' Nom.
  • Approximate Cable Weight: 75 Lbs/1M' Nom.
  • Flame Rating: UL 1685 Vertical Tray

Electrical & Environmental Properties:

  • Temperature Rating: -20deg C to 90deg C
  • Operating Voltage: 300 V RMS
  • Max.Capacitance Between Conductors @ 1 KHz: 28 pf/ft Nom.
  • DC Resistance per Conductor @ 20deg C: 4.2 Ohms/1M' Nom.
  • Insulation Colors: Black, Red, Brown, Blue
  • Jacket Color: Black
  • RoHS Compliant: --
  • TIA455-82B Water Infiltration Test Compliant: Yes
  • UL 444 & 13 Compliant: Yes

Mechanical Properties:

  • Max. Recommended Pull Tension: 108 lbs.
  • Min. Bend Radius (Install): 3.5”
