Jensen Loudspeakers P-A-C12R-8
12" 25W Vintage Ceramic Speaker

OUR PART #:  P-A-C12R-8

Jensen Loudspeakers' P-A-C12R-8 offers warm low and mid response with smooth/bright highs. When presented with overdrive distortion, it presents smooth crunch with low-end focus.
Learn More
Selected Model Price: $63.29
List Price: $87.30
Save up to 28%!
Write the first review.
Jensen Loudspeakers P-A-C12R-8
Select a Model: (shipping times are approximate)

Related Products

Jensen Loudspeakers' P-A-C12R-8 offers warm low and mid response with smooth/bright highs. When presented with overdrive distortion, it presents smooth crunch with low-end focus.

Jensen Loudspeakers P-A-C12R-8 Specifications:

  • General Characteristics:
    • Nominal Overall Diameter: 12" (306 mm)
    • Nominal Voice Coil Diameter: 1.0" (25 mm)
    • Magnet Weight: 10 oz (270 g)
    • Overall Weight: 3.10 lbs
    • Flux Density: 1.0 T
  • Thiele-Small Parameters for 8O:
    • Voice Coil DC Resistance RE: 6.50 O
    • Resonance Frequency ƒS: 74.0 Hz
    • Mechanical Q Factor QMS: 21.48
    • Electrical Q Factor QES: 2.06
    • Total Q Factor QTS: 1.88
    • Mechanical Moving Mass MMS: 24.6 g
    • Mechanical Compliance CMS: 187 µm/N
    • Force Factor BxL: 5.98 Wb/m
    • Equivalent Acoustic Volume VAS: 63.2 lt.
    • Maximum Linear Displacement XMAX: 0.8 mm
    • Reference Efficiency nO: 1.2 %
    • Diaphragm Area SD: 490.8 cm2
    • Losses Electrical Resistance RES: 67 O
    • Voice Coil Inductance @ 1kHz LE: 0.49 mH
  • Constructive Characteristics for 8O:
    • Magnet: Ferrite
    • Voice Coil Winding: Copper
    • Voice Coil Former: Kapton
    • Cone: Paper
    • Surround: Integrated Paper
    • Dust Dome: Felt
    • Basket: Pressed Sheet Steel
  • Electrical Characteristics for 8O:
    • Nominal Impedance: 8 O
    • Rated Power: 25 W
    • Musical Power: 50 W
    • Sensitivity @ 1W,1m: 93.8
