SoundTube SM890I-WH SM890i 8" 150 Watt High-SPL Surface Mount Speaker in White

OUR PART #: SM890I-WH MFR #: SOUSM890IWH

Copied to clipboard

The Soundtube SM890i is a premium high-SPL, high-efficiency surface-mount loudspeaker for distributed or 8 ohm systems. ...Read more

SoundTube SM890I-WH SM890i 8" 150 Watt High-SPL Surface Mount Speaker In White Image 1
SoundTube SM890I-WH SM890i 8" 150 Watt High-SPL Surface Mount Speaker In White
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The Soundtube SM890i is a premium high-SPL, high-efficiency surface-mount loudspeaker for distributed or 8 ohm systems. The SM890i incorporates a dedicated 8-inch treated fiber woofer and a high-power compression horn transducer with a BroadBeamHP® waveguide to deliver a consistent dispersion pattern and superb intelligibility for the foreground music, sound reinforcement and PA markets.

The SM890i uses a 150-watt low-insertion loss transformer and a six-position tap switch with a transformer bypass position. Mounting hardware includes SoundTube’s proprietary tool-free, low profile Stealth™ bracket with an integrated internal wedge cam, which allows for stable and precise aiming from 0 to 90 degrees. Corrosion-resistant materials, including powder-coated steel grille plus all-aluminum mounting hardware make the SM890i ideal for indoor/outdoor use.

Soundtube SM890i Specifications:

  • System Type: 8-inch offset, surface mount, ported, high power (150-watt transformer for 25/70.7/100-volt or transformer bypass)
  • Impedance (nominal): 8 ohms
  • Sensitivity dB @ 2.83 V/1 m: 93.0 dB
  • Sensitivity dB @ 1 W/1 m: 93.0 dB
  • Frequency Response (-3 dB): 100 Hz - 22 kHz
  • Frequency Response (-10 dB): 63 Hz - 22 kHz
  • Max. Program Power: 300 W
  • Max. Continuous Power RMS: 150 W
  • Max. Power SPL @ 1 m: 115.0 dB
  • Coverage Angle (-6 dB @ 2 kHz): 110 Degree Vertical; 80 Degree Horizontal
  • Coverage Angle (-6 dB @ 10 kHz): 110 Degree Vertical; 80 Degree Horizontal
  • Coverage Angle (averaged 2-10 kHz): 110 Degree Vertical; 80 Degree Horizontal
  • Angle of Pointability: 0 to 90 Degrees Horizontal
  • Directivity Factor (Q): 5.0 dB (averaged 100 Hz - 10 kHz); 8.0 dB (2 kHz)
  • Directivity Index (DI): 5.0 dB (averaged 100 Hz - 10 kHz); 8.0 dB (2 kHz)
  • Tap Selector: Six-position rotary switch with transformer bypass
  • Transducer - Low Frequency Driver: 8" (203 mm) treated paper cone with treated cloth surround
  • Transducer - High Frequency Driver: 1.42" (36 mm) titanium compression driver with waveguide
  • Low-Frequency Voice Coil: 1.34" (34 mm)
  • Crossover Frequency: 2.5 kHz
  • Network Type - Low Pass: 12 dB per octave, 2nd order
  • Network Type - High Pass: 12 dB per octave, 2nd order
  • Enclosure Material: Injection-molded ABS, glass fiber reinforced
  • Grille: Powder-coated steel
  • Inputs: Four-pin, 5.08 mm Euroblock for individual or daisy chain connection
  • Color: White
  • Height: 18.78" (477.0 mm)
  • Width: 11.65" (295.9 mm)
  • Depth (Including Bracket): 15.37" (390.4 mm)
  • Weight: 21.0 lbs. (9.5 kg)
  • Included Accessories:
    • Surface Mount Brack
    • Safety Cable
    • Euroblock Connector
    • Terminal Weather Boot
    • Paint Mask
  • Regulatory - CE: Approved
  • Regulatory - UL: UL1480 (UEAY)|Listed
  • RoHS: Approved

Note:

Image shown above is for illustrative purposes only; actual product comes in White. For more information on this and other products, contact your Sales Representative.
