Liberty AV Solutions 23-MINI-CMP-BLK
Serial digital Mini-RG59 dual shield 4.5 GHz plenum coaxial cable

OUR PART #:  23-MINI-CMP-BLK

The Liberty 23-MINI-CMP-BLK is a 23 AWG solid core dual shielded mini-RG59 serial digital coaxial cable NEC type CMP and CEC type CMP FT6.
Learn More
Our Price: $727.20
List Price: $808.00
You save 10%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Liberty AV Solutions 23-MINI-CMP-BLK
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The Liberty 23-MINI-CMP-BLK is a 23 AWG solid core dual shielded mini-RG59 serial digital coaxial cable NEC type CMP and CEC type CMP FT6. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725, 800 and 820.

Liberty 23-MINI-CMP-BLK Features and Benefits:

  • 23 AWG solid annealed bare copper conductor
  • Gas-injected cellular fluoropolymer dielectric
  • 100% coverage aluminum/poly/aluminum foil inner shield
  • 95% coverage tinned copper braid shield
  • Plenum rated PVC jacket
  • 4.5 GHz sweep, very low loss, excellent SRL
  • NEC CMP, CEC CMP FT6, RoHS compliant
  • 1000 foot spools

NOTE:  For detailed specifications on this product, see attached specification sheet under the Documentation Tab.

Applications:

  • SMPTE Serial Digital Video, AES3id Digital Audio
  • S/PDIF digital audio, Subwoofer audio
  • All Base Band Video and Unbalanced Analog Audio
  • RF Modulated Signals, CATV, DBS, MATV
