TMB A.leda B-EYE K20
LED Wash and Beam Light with Moving Head Projector


TMB carries the A.LEDA B-EYE K20 which is a RGBW wash-light that generates beautiful colors and features a remarkable, wide 6° to 60° beam aperture.
Learn More

Call for price! Not available online.
List Price: $11,415.29

Similar Products

TMB carries the A.LEDA B-EYE K20 which is a RGBW wash-light that generates beautiful colors and features a remarkable, wide 6° to 60° beam aperture. In addition, the A.leda B-EYE K20 has introduced a startling feature that transforms it into a stunning effect light: the front lens can be rotated in either direction and at variable speed, creating many little beams that can be unfolded or closed like petals!

Truly innovative for its unique lighting effects, the A.leda B-EYE K20 features unmatched versatility, making it a fantastic creative tool. Firstly, it's an excellent wash-light, with beautiful colors and an impressive 6° to 70° zoom. The beam however can be closed further down to as little as 4°, switching the light from wash diffusion into a parallel beam. It thus becomes a beam-light for amazing aerial effects, and can generate a pulsating bundle of individually controllable micro-beams, each with its own colors and shades. Adding colors and dynamic patterns, the A.leda B-EYE K20 turns into a unique effect light, generating countless kaleidoscopic projections.

A.leda B-EYE K20 Features:

  • Source Type: RGBW LEDs
  • LED Nominal Wattage: 15W
  • Number of LEDs: 37
  • Versatile, three (3) operating modes: wash, beam, graphic
  • Unique optical system, featuring unmatched zoom range (4°-60°) and even light spread
  • Individual LED control for each parameter
  • invisible front grid
  • Beam edge softening control (in wash mode)
  • Exclusive parallel beam consisting of an array of individually controllable micro-beams
  • Enhanced electronic engine for dynamic beam pattern design, with digital accuracy and repeatability
  • Rotating front lens for countless kaleidoscopic effects, for aerial or projection use
  • White CT Emulation 2500-8000K
  • RGB auto-tuning to lamp CT Emulation
  • Tungsten Lamp Emulation

A.leda B-EYE K20 Specifications:

  • Power Supply: 100-240V 50/60Hz
  • Input Power: 750VA
  • Lamp Source:
    • 37 Osram Ostar RGBW LEDs
    • LED Nominal Wattage: 15W
    • LED Average Life: 50,000 h
  • Optics: 4°-60° Electronic Zoom Range
  • Effects Section:
    • Three (3) operating modes: Wash, Beam, FX (Kaleido effects)
    • Bi-directional Rotating Front Lens
    • Digital Wash-Beam Framing effect
    • Beam edge softening control (in Wash mode)
    • Pixel Patterning Macros with enhanced control
    • 0-100% linear electronic dimmer
    • Adjustable speed stop/strobe effect, with instantaneous blackout
    • Dedicated channel for color temperature setting
    • White CT Emulation 2500-8000K
    • RGBW auto-tuning to lamp CT Emulation
    • Tungsten Lamp Emulation
    • Slow Strobe: 1 flash/sec; Fast Strobe: 25 flash/sec
  • Control and Programming:
    • Control channels: 21 in standard mode
    • DMX protocol signal: USITT DMX 512
    • Art-Net / RDM
    • Display: Graphic LCD backlit b/w Display
    • Pan/Tilt Resolution: 16 bit
    • Dimmer Resolution: 16 bit
    • Movement control: vectorial
    • DMX signal connection: 3 and 5 pole XLR input and output
    • Software upload through DMX input
  • Body
    • Aluminium structure with die-cast plastic cover
    • Two (2) side handles for transportation
    • PAN lock for transport and maintenance
  • Moving Body:
    • Movement by means of two (2) stepper motors, controlled by microprocessor
    • Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit
    • Travel:
      • PAN = 540°
      • TILT = 210°
  • Electronics:
    • Long-life auto-charging buffer battery
    • Preset color and graphic effect macros
    • Function reset controllable from a central control unit
    • Menu-driven internal self-test function
    • Ethernet ready with RJ45 socket
    • Display: backlit black-and-white graphic LCD display
    • Electronic check-up of every single parameter with error alarm
    • DMX level monitoring on each channel
    • Automatic internal data transmission error diagnostics
    • Firmware upgrade even when the unit is not connected to the power supply
    • Firmware transfer from one light to another
  • Safety Devices:
      • Automatic power safety derating in case of overheat of the LED board
      • Forced ventilation
  • Working Position:
    • Works in any position
    • Hanging system: with fast-lock omega clamps (1/4 turn) on the base
  • CE Marking:
    • In conformity with the European Directives:
      • 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
      • 2014/30/EU - Electromagnetic Compatibility (EMC)
      • 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)
      • 2009/125/EC - EcoDesign requirements for Energy-related Products (ErP)
  • ETL:
    • This product is available, on demand, with cETLus Listed Mark, that complies with the UL 1573, UL 8750 and CSA C22.2 No. 166 standards.
  • Physical:
    • Weight: 46.3 lbs (21 kg)
    • Dimensional Illustration:

A.leda B-EYE K20
