Interactive Technologies ST-HUB
CueStation Unversal Hub via RS-232

OUR PART #:  ST-HUB

Our Price: $461.16
List Price: $549.00
You save 16%!

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Interactive Technologies ST-HUB
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The ST-HUB is a CueStation Universal Network Hub from Interactive Technologies that is a multi-purpose interface for controlling button stations that use either 2-Wire or 5-Wire network technologies. The Hub acts as both a power supply for the stations as well as a gateway for allowing host systems to receive button events and instruct the button indicators to illuminate in various ways. The Network Hub is not used with Passive stations.  The Network Hub (without Ethernet) communicates with the host system by RS-232 messages.

Perfect for adding networkable CueStations to a CueServer system, or for custom projects.

Interactive Technologies ST-HUB Includes:

  • CueStation Universal Network Hub
  • Power Supply
  • Mounting Flanges
  • Instructions

Interactive Technologies ST-HUB Features:

  • Controls both 2-Wire and 5-Wire CueStations
  • Communicates with the host system via RS-232
  • Powered by 12-24V AC or DC
  • Removable terminal blocks
  • Small size

Interactive Technologies ST-HUB Specifications:

Connections

  • Power Input: 2.1 mm DC Power Input Jack or 2-PositionPluggable Terminal Block
  • Ethernet Port: None
  • Serial Port: Female DB-9 or 3-Position PluggableTerminal Block
  • 2-Wire Network Port: 2-Position Pluggable TerminalBlock
  • 5-Wire Network Port: 5-Position Pluggable TerminalBlock
  • Auxiliary Port: 3-Position Pluggable Terminal Block (not currentlyused)

Power Requirements

  • Input Voltage:  12-24V AC orDC
  • Input Current:
      -  4 Watts + 0.6 Watts perStation
      -  333mA + 50mA per Station (using 12V)
     -  167mA + 25mA per Station (using 24V)

Physical

  • Width:
      -  4.29" (109 mm) without mountingflanges
      - 5.51" (140 mm) with mounting flanges
  • Length:  3.43" (87 mm)
  • Height:  1.18" (30 mm)
  • Weight:  0.7 lbs. (0.3 Kg)

Environmental

  • Operating Temp:  -40° to 158° F (-40° to 70°C)
  • Storage Temp:  -40° to 176° F (-40° to80°C)
  • Relative Humidity:  5% to 95%noncondensing
  • Altitude:  10,000 feet maximum
