Galaxy Audio JIB/PA50
50W Class D Commercial Amplifier

OUR PART #:  JIB/PA50

Galaxy Audio's JIB/PA50 is designed to meet the demands of the school, commercial, industrial, and pro audio installations.
Learn More
Our Price: $159.99
List Price: $224.99
You save 29%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Galaxy Audio JIB/PA50
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

Galaxy Audio's JIB/PA50 is designed to meet the demands of the school, commercial, industrial, and pro audio installations. Its compact and lightweight form allow for a wide range of applications that need noiseless amplification. The JIB/PA50 has a 50 Watt (2x25W) Energy-Star rated Class D amplifier in only a quarter rack width design. This design allows for the amplifier to be placed where conventional amplifiers cannot be.

The three stereo inputs, microphone input, and separate line and mic gain adjustments allow for connecting the JIB/PA50 to a projector, wireless microphone receivers, and other sound sources quickly. The Energy-Star amplifier automatically goes into standby mode if no input signal is sensed for 20 minutes, dropping power consumption to only 0.8W, saving energy and money, while extending the JIB/PA50 life span.

Galaxy Audio JIB/PA50 Features:

  • Output 50 watt (25 watts RMS per channel)
  • Three stereo inputs, two on RCA connectors and one on3.5mm stereo jack
  • Balanced sub-line level input summed to both channels
  • Stereo input can be controlled externally with 10Kpot
  • Energy-efficient amplifier

Galaxy Audio JIB/PA Specifications:

  • Audio Throughput
    • Frequency response: 20 Hz to 20 kHz, +/-1 dB @ 1 watt
    • S/N: >80 dB 20-20k Hz at maximum output
  • Audio Inputs
  • 3 line level inputs: Stereo unbalanced; 2 on a pair of RCA connectors each; 1 on 3.5mm stereo mini jack; all 3 mixed together pre-volume control
  • Impedance: >18 kOhms unbalanced
  • Nominal level: -10 dBV (316 mV)
  • Maximum level: +20 dBV (10 V) at 1% THD
  • Input level sensitivity: -10 dBV (316 mV)
  • 1 sub Mic inputs: Balanced; on 3.5 mm stereo minijack; mixed evenly to left and right channels post volume control
  • Impedance: >18 kOhm unbalanced
  • Nominal level: -30 dBV (31.6 mV)
  • Maximum level: +20 dBV (10 V) at 1% THD
  • Input level sensitivity: -30 dBV (31.6 mV)
  • Audio Output
  • Speaker outputs: Stereo speaker output on phoenix block connectors optimized for 18 AWG wire
  • Amplifier type: Class D
  • Output power: Continuous power with full load and 1%THD
    • @ 4 Ohm: 25 Watts rms per channel
    • @ 8 Ohm: 14 Watts rms per channel
  • Damping factor: >30
  • Automatic Standby: Standby mode activates if no input signal is detected for 20 minutes. Once an input signal is detected the unit resumes normal function.
  • Dimensions: 1.7" x 4.3" x 3" (43 x 109 x 76 mm)
  • Weight: 0.77 lb (350 g)
