SoundTube RF31-EZ-T
3" Full-Range Raw-Frame Ceiling Speaker in White


Call for price! Not available online.

The RF31-EZ-T is a premium full-range 3-inch speaker with 10 w integrated transformer for applications requiring 8 ohm audio solutions.Integrated 10w transformer. One 3-inch full-range high-excursion, weather-resistant, high-fidelity polypropylene driver with butyl rubber surround and neodynium magnet. Ultra-compact design with a total visible footprint of 4.75-inch square. Weatherized components for indoor/outdoor applications. Corrosion-resistant, powder-coated aluminum grille with snap fit attachment. Rapid installation into dual-gang junction box using four stainlees steel screws (junction box not included). UL 1480 (UEAY) listed. Included accessories: Paintable white aluminum snap-on grille, paint mask, and four stainless steel mounting screws. Transformer does not include 8 ohm bypass.


  • Frequency Response (-3 dB): 170 Hz – 14 kHz
  • Low Frequency(-10 dB): 82 Hz- 22 kHz
  • Sensitivity: 85.0 dB
  • Power Capacity RMS: 20 W
  • Max SPL dB @ 1 M: 95 dB
  • Transformer Options: 25 / 70.7 / 100 Volt option, no 8 Ohm bypass.
  • Full-Range Driver: 76.1 mm (3.0 in.) Polypropylene driver w/ butyl rubber surround
  • Woofer: Optional subwoofer SM1001p
  • Connections: Five-position terminal block
  • Visible Height: 4.75"
  • Visible Diameter: 4.75"
  • Weight: 1.3 lbs
  • Optional Accessory: Theft-resistant stainless steel grille (AC-RF31-TRG) and 10" powered subwoofer (SM1001p)
