Sony SRG-300H Full HD Desktop and Ceiling Mount PTZ Camera

OUR PART #: SRG300H

Copied to clipboard
Sony SRG-300H Full HD Desktop And Ceiling Mount PTZ Camera Image 1
Sony SRG-300H Full HD Desktop And Ceiling Mount PTZ Camera Image 2
TC8whp3O3BA
2 Videos
Sony SRG-300H Full HD Desktop And Ceiling Mount PTZ Camera
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The Sony SRG-300H desktop and ceiling mount remote operated PTZ camera with powerful 30x optical zoom and 60fps delivers stunning image quality coupled with smooth robotic control. This PTZ camera captures high-quality color video images in corporate boardrooms, lecture halls, and training suites. The pictured model is encased in black housing, it is also available in white (item: SRG-300H/W). Contact your Full Compass Sales Pro for more information.

Superior low-light sensitivity (as low as 0.35 lx in High Sensitivity mode) makes this camera ideal for use in near-dark conditions. Sony's View-DR technology expands dynamic range for clear images under difficult back lighting with extreme light and dark in the same scene. XDNR™ technology is used for noise reduction and crisp reproduction of still and moving objects in poorly-illuminated rooms, even when digital zoom is engaged.

The camera's wide FOV makes it easier to cover the whole room during video conferences. Smooth, silent PTZ operation with 16 preset camera positions makes it quick and easy to re-frame shots without disturbing presenter or other audience members. Powerful 30x optical zoom combined with 12x digital zoom for high-quality close-ups of distant subjects – such as a lecturer on the far side of a large auditorium.

PTZ Camera Includes

  • SRG-300H unit
  • AC Power Adapter
  • AC Power Cord
  • IR Remote Commander Unit
  • RS-422 Connector Plug
  • Ceiling Brackets (2)
  • Operating Instructions

Sony SRG-300H Features

  • Full HD Image Quality with 60fps Frame Rate - See every participant or presenter clearly. The 1/2.8-type Exmor CMOS image sensor captures smooth, crisply detailed, Full HD (1920 x 1080 60p) images with minimal noise – even in low light.
  • View-DR Plus XDNR Technology for clear pictures in any lighting condition - Sony's View-DR technology expands dynamic range and XDNR technology reduces image noise on moving objects or in poorly-lit rooms.
  • Powerful 30x Optical Zoom, 12x Digital Zoom - for frame-filling close-ups in high detail. Responsive auto-focus ensures that images stay clear and sharp at high zoom settings.
  • Fast, Quiet PTZ Operation - A powerful direct drive motor assures quiet, smooth, rapid movement to the target position over a wide pan/tilt angle range.
  • Wide 65-degree Viewing Angle - See every participant in a boardroom with a wide 65° horizontal viewing angle.
  • Desktop or Ceiling Mount - Image E-flip gives extra operating flexibility, allows a table-top or ceiling mount while maintaining proper image orientation.
  • Versatile Connectivity Options - Support for RS-232C/RS-422 protocols allows easy connection to a wide range of peripheral products. The camera can also be controlled via VISCA protocols over a standard IP network.
  • HDMI Compatible - HDMI video interface simplifies direct connection to a compatible video conferencing system, PC, or HD monitor.
  • 16 Position Presets - Allow quick transition from one camera position to another (controllable via IP or VISCA).
  • Easy Control via PC - PC control software allows remote adjustment of basic and advanced camera settings via VISCA protocols - such as color adjustment and Pan/Tilt speed - from an intuitive interface.

Specifications

  • Camera
    • Image Device: 1/2.8 Exmor CMOS
    • Lens: 30x Optical/12x Digital Zoom Lens
    • Focal Length: f=4.3mm (wide) to 129mm (tele)
    • Focal Length - F: F1.6 to 4.7
    • Minimum Object Distance: 10mm (wide end) / 1200mm (tele end)
    • Shutter Speed:
      • 1/1 to 1/10000 sec (59.94 Hz system)
      • 1/1 to 1/10000 sec (50 Hz system)
    • White Balance: Auto, Indoor, Outdoor, One-Push Auto, ATW, Manual
    • Pan Angle/Speed Angle: +/- 170°
    • Speed: 100°/sec
    • Tilt Angle/Speed Angle: +90° / -20°
    • Speed: 90°/sec
    • Horizontal Viewing Angle: 65° (wide)
    • Preset Positions: 16 presets
  • Control Interface:
    • VISCA protocol with built-in IP control
    • Camera Control Interface: RJ-45 / RS-232C / RS-422
  • Video Output
    • Minimum Illumination: 1.4 lx (50 IRE, F1.6, 30 fps)
    • S/N Ratio: 50 dB
    • Video Output: HDMI
  • Signal System:
    • 1080/59.94p, 50p, 29.97p, 25p
    • 1080/59.94i, 50i
    • 720/59.94p, 50p, 29.97p, 25p
  • Housing Color: Black
  • Dimensions (W x H x D): 6-1/4" x 6-1/2" x 6-1/2" (157 x 164 x 163mm)
  • Weight: 3 lbs, 3.4 oz (1.4 kg)
  • Power Requirements: DC 12V (DC10.8 - 13.2V)
  • Power Consumption: 16.8W
  • Operating Temperature: 32°F to +104°F (0°C to +40°C)
  • Storage Temperature: -4°F to +140°F (-20°C to +60°C)

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Product Documents

Click to download

Product Videos
