Product Overview
The X515C from Lex Products is a NEMA 5-15, 15 Amp, 2 Pole, 3 Wire, 120 VAC Lex Loc Edison female connector. This female connector is intended for use on extension cords.
Applications:
- Theatrical
- Motion Picture
- Live Events
- Industrial
- Military
Lex Products Corp. X515C Features:
- Cage clamp terminations cannot loosen, eliminating the main cause of device failure
- No tools needed for wire termination. Simply open and close the terminals.
- Two fast-travel assembly screws and terminal design saves time and reduces labor requirements
- All-black color blends into scenery
- External cord clamp design provides excellent strain relief for a wide range of cord sizes
Lex Products Corp. X515C Specifications:
- CONSTRUCTION
- Housing and Body: Nylon – Tough and resistant to a wide range of chemicals. UL Recognized for 125°C continuous use. UL 94V-2
- Flammability Index. Beveled design to resist snagging.
- Blades and Contacts: Solid brass for excellent conductivity
- Terminal Cover: Clear polycarbonate – terminals visible
- Assembly Screws: Two U-drive combination slot/crosshead
- MECHANICAL
- Accommodates 18/3 SJ through 10/3 S cable
- Cord Accommodation (with inserts): .300''- .430''
- Cord Accommodation (inserts removed): >.430''- .655''
- ELECTRICAL
- Dielectric Withstand Voltage: >3,000V
- Heat Rise: Maximum 30°C after 100 cycles at 150% of rated current
- Current Interrupting: Yes
- U.L.Listed File EE322951
- C.S.A.Cer tified File LR81290
NOTE:
Actual product may vary in appearance and specification. For more information on this and other products, please contact your Sales Pro.
