Inter-M Americas Inc QD-4480
4 x 80W Quad Channel Amplifier

OUR PART #:  QD-4480

The Inter-M Americas Inc QD-4480 is a quad, four channel power amplifier capable of driving 4 Ohm loads.
Learn More
Our Price: $733.09
List Price: $806.40
You save 9%!
Write the first review.
Inter-M Americas Inc QD-4480
Usually ships in 7-14 business days.
Need it sooner? Call us!

Related Products

The Inter-M Americas Inc QD-4480 is a quad, four channel power amplifier capable of driving 4 Ohm loads. Their clean sound quality makes them ideal for permanent installation in professional PA systems or for portable use for live performances. Primarily designed for multi-zone use such as in bars and restaurants, where separate control of the music in several areas is required, these designs may be applicable for use in any situation where a number of low-power amplifiers are required, such as for cue-feeds, effects-loudspeakers, museum displays etc. Three models are available; each combines four separate low-impedance amplifiers in a single 2U rack-mounted case. Each amplifier has an individual input XLR/TRS "Combo" balanced input connector, a level-control with associated signal-present and clip LED’s, and 5 way binding-post speaker output terminals. For added versatility, an input-selector switch allows each pair of amplifiers to be driven either separately (stereo), with inputs in parallel (dual mono), or bridged into mono. Clip-limiters are supplied on each channel to help prevent distortion due to excessive signal levels. All units have soft-start protection circuitry and feature power, signal, protection, and clip indicators on the front panel. These amplifiers are fan-cooled with circuit-protection and turn-on delay. The quad series amplifiers are powered by 100-120VAC or 220-240VAC 50/60Hz (depending on country requirements).

NOTE: The image shown is for illustrative purposes only. Actual product appearance may vary.

Inter-M Americas Inc QD-4480 Features:

  • QD-4480: 80W @ 4 Ohms per Channel
  • Inputs: Balanced Combo Jacks
  • Outputs: Five-Way Binding Posts
  • <0.03% Total Harmonic Distortion
  • Extensive Protection Circuitry
  • Two-Speed Cooling Fan
  • LED Indicators: Power, Signal, Protection, Clip
  • Rack Mount (2RU)

Inter-M Americas Inc QD-4480 Specifications:

  • Power Output
    • 4 Ohms (Quad Ch): 80W
    • 8 Ohms (Quad Ch): 120W
    • 8 Ohms Bridged Mono: 240W
  • Input Sensitivity (8 Ohms , 1kHz): 0.775Vrms
  • Input Impedance: 20k Ohms Balanced
  • Slew Rate ( 8 Ohms , Full Swing): ± 30V/ µsec
  • Frequency Response ( ±0.5dB): 20Hz - 50kHz
  • THD: <0.03%
  • Signal-to-Noise Ratio: 105dB
  • Damping Factor (8 Ohms, 1kHz): >100
  • Residual Noise: -85dB
  • Channel Separation (8 Ohms , 1kHz): 80dB
  • Voltage Gain (4 Ohms): 26dB
  • Power Source: 100-120VAC or 220-240VAC
  • Power Consumption: 300W
  • Weight (SET) 30.8lb (11.5kg)
  • Dimensions (SET)(WxHxD): 19" x 3.5" x 14.5"
