Neutrik NAC3MX-W
Locking Power-In Male Cable Connector with Screw Terminals

OUR PART #:  NAC3MX-W

The Neutrik NAC3MX-W powerCON TRUE1 is a locking waterproof 16/20 A true mains connector.
Learn More
Our Price: $8.55
List Price: $11.85
Save up to 39% when you order by quantity!
  • Buy 25: $7.72 each.
  • Buy 50: $7.45 each.
  • Buy 100: $7.18 each.

4.5 / 5

★★★★★ 2 Reviews. Write Yours

Related Products

The Neutrik NAC3MX-W powerCON TRUE1 is a locking waterproof 16/20 A true mains connector. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection.

The NAC3MX-W is a connector with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live.

Neutrik NAC3MX-W powerCON TRUE1 Features:

  • True mains connector with breaking capacity (CBC)
  • Lockable 16 A single phase connector (USA: 20 A)
  • Dust and water resistant according to IP65 in mated condition
  • Easy and reliable twist lock system
  • Extremely robust and reliable
  • Unique Neutrik cable retention
  • ENEC certified according to IEC 60320
  • UL recognized components

Neutrik NAC3MX-W powerCON TRUE1 Specifications:

  • Electrical
    • Contact resistance: = 3 mO (inner)
    • Dielectric strength: 4 kVdc / 2.8 kVac
    • Insulation resistance: 0,1 GO (after damp heat test IEC 68-2-30)
    • Number of electronical contacts: 2 + PE
    • Rated current per contact: 16 A rms (USA: 20 A)
    • Rated voltage: 250 V AC
  • Mechanical
    • Cable O.D.: 6 - 12 mm
    • Lifetime: > 5000 mating cycles
    • Wiresize: 1.0 - 2.5 mm²
    • Wiresize: 12 AWG
  • Material
    • Contact plating: 2 µm Ag
    • Contacts: CuNi1Si0.2
    • Insert: Polyamide (PA 6.6 30 % GR)
    • Locking element: ZuAl4Cu1
    • Shell: Polyamide (PA 6.6 30 % GR)
    • Strain relief: Polyacetal (POM)
  • Environmental:
    • Flammability: UL 94 V-0
    • Protection class: IP 65 (mated)
    • Temperature range: -30 °C - +80 °C

4.5 / 5

★★★★★

Reviewed by 2 customers.
(2 are Verified Buyers.)

Write a Review

Display Only Verified Reviews

1
1
0
0
0

There are no reviews to display with the selected filters.

Todd k on 03/14/2018 ✔ Verified

This reviewer left no comment.

0 Comments / Add a Comment

This cannot be empty.
This cannot be empty.
This cannot be empty.
Please Enter your First Name Please Enter your Last Initial
This cannot be empty.

500 characters remaining

Please Enter your Feedback

Thank you for submitting your comment. It is in a queue to be moderated.

Eric G on 02/07/2018 ✔ Verified

Great alternative to Nema locking plugs. Note that the HTAC tool is a must-have to assemble these.
