EAW VFR129I-WHITE 12" 2-Way Speaker Full-Range Speaker In White Image 1
EAW VFR129I-WHITE 12" 2-Way Speaker Full-Range Speaker In White
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The VFR129i two-way, full range loudspeaker system includes a direct radiating, vented, 12" LF cone transducer and a 1" exit / 1.75" voice coil HF compression driver loaded with a large, square, user-rotatable 90x60 or 60x45 coverage pattern horn built on the classic MK Series horns. These horns deliver exceptional high frequency dispersion, and their square shape lets users “rotate the enclosure around the horn” to maintain directivity in a horizontal configuration. The standard horn is field replaceable with an optional 60x45 horn. This change incorporates a passive filter adjustment to maintain consistent acoustic response and smooth beamwidth throughout the crossover region.

Because VF Series full range systems (VFR/VFM) use HF sections similar to those developed for the MK Series, EAW engineers could employ the same revolutionary “beamwidth-matching” internal passive crossover/filter networks that set the MK Series apart from all other two-way systems. If powered by an EAW-specified amplifier or via a UX Series digital signal processor, the VFR129i can enjoy the benefits of EAW Focusing, a technology that eliminates the anomalies inherent in the time domain of any loudspeaker.

The VFR129i white, installation-only versions omit handles and the pole-mount cup but include NL4 connector, barrier strip connector, an optional transformer, and multiple mounting points. The new design leaves the enclosure sides completely smooth and attractive. Optional rigging hardware is available for preconfigured arrays with VFS sub bass systems.

Features:

  • Two-way, full range loudspeakers
  • Beamwidth-matching crossover point
  • Large, user-rotatable horn for optimized pattern control

Specifications:

  • Subsystem:
    • Transducer/Loading
      • LF 1× 12", cone / Vented
      • HF 1× 1" exit, 1.75" voice coil compression driver / Horn-loaded
    • Operating Mode:
    • Amplifier Channels / External Signal Processing: Single-amp LF/HF High pass filter
  • Performance:
    • Operating Range: 50 Hz to 20 kHz
    • Nominal Beamwidth:
      • Horz 90°
      • Vert 60°
    • Axial Sensitivity (whole space SPL): LF/HF 96 dB / 50 Hz to 20 kHz
    • Input Impedance (ohms):
      • Nominal / Minimum: LF/HF 8 / 6.5@ 140 Hz
    • Input Taps (With ACC-TXVFR Transformer installed):
      • 70V / 100V
      • LF/HF: 128W, 64W, 32W,16W / 128W, 64W, 32W
    • High Pass Filter: High Pass = >55 Hz, 12 dB/octave Butterworth
    • Accelerated Life Test: LF/HF:63.2 V / 500 W @ 8 ohm
    • Calculated Axial Output Limit (whole space SPL): LF/HF: 123dB / 129dB
  • Dimensions (inches/millimeters)
    • Height: 25.69/659
    • Width (front): 16.2/412
    • Width (rear): 7.8/199
    • Depth: 16.4/417
    • Trap. Angle (degrees per side): 15
  • Weights (pounds/kilogram)
    • Net: 54lbs/24.5

Note:

The image shown is for illustrative purposes only. Actual image color is WHITE.
