Quam SYSTEM6VPS
Wallmount Speaker Assembly in Stainless Steel Finish

OUR PART #  SYSTEM-6-VPS

Our Price: $185.15
List Price: $269.90
You save 31%! (Low Price Guarantee)
Usually ships in 7-14 business days.
Need it sooner? Call us!

The SYSTEM 6VPS is a complete loudspeaker assembly with a double re-entrant horn, compression type loudspeaker, 16W- 25/70V transformer, BS8VPS baffle (stainless steel, vandal resistant, powder-coated white) and a SE1WVPS surface mount enclosure stainless steel, vandal resistant, powder-coated white). Mounting hardware is #8-32 ’pin-in-torx’.

System Components:

  • Loudspeaker H16
  • Transformer Integral to unit 25/70V 16W-5 tap Color Coded Leads (16W, 8W, 4W, 2W, 1W)
  • Baffle BS8VPS - stainless steel, vandal resistant, powder-coated white
  • Enclosure SE1WVPS - Square, stainless steel, vandal resistant, powder-coated white, interior and exterior use

Applications:

  • Indoor or protected outdoor environment
  • Installation.....Horizontal or vertical surface mount
  • Program Material.....Paging and signal tones

Specifications:

  • Average Sensitivity 110 dB SPL, 1W/ 1M
  • Loudspeaker Power Rating 16W RMS, EIA 426A Standard
  • Calculated Output 121dB SPL, 5W/ 1M
  • Magnet Type & Weight BeFe Ceramic, 10 oz. Nominal
  • Frequency Response 350Hz - 10 kHz EIA 426A Standard
  • Nominal Coverage Angle 90° Included Angle, -6 dB / 2 kHz, half space
  • Audio Connection 7" color-coded pigtails, pre-cut



Click to download

Quam SYSTEM6VPS
Wallmount Speaker Assembly in Stainless Steel Finish

OUR PART #  SYSTEM-6-VPS

Product Information:

The SYSTEM 6VPS is a complete loudspeaker assembly with a double re-entrant horn, compression type loudspeaker, 16W- 25/70V transformer, BS8VPS baffle (stainless steel, vandal resistant, powder-coated white) and a SE1WVPS surface mount enclosure stainless steel, vandal resistant, powder-coated white). Mounting hardware is #8-32 ’pin-in-torx’.

System Components:

  • Loudspeaker H16
  • Transformer Integral to unit 25/70V 16W-5 tap Color Coded Leads (16W, 8W, 4W, 2W, 1W)
  • Baffle BS8VPS - stainless steel, vandal resistant, powder-coated white
  • Enclosure SE1WVPS - Square, stainless steel, vandal resistant, powder-coated white, interior and exterior use

Applications:

  • Indoor or protected outdoor environment
  • Installation.....Horizontal or vertical surface mount
  • Program Material.....Paging and signal tones

Specifications:

  • Average Sensitivity 110 dB SPL, 1W/ 1M
  • Loudspeaker Power Rating 16W RMS, EIA 426A Standard
  • Calculated Output 121dB SPL, 5W/ 1M
  • Magnet Type & Weight BeFe Ceramic, 10 oz. Nominal
  • Frequency Response 350Hz - 10 kHz EIA 426A Standard
  • Nominal Coverage Angle 90° Included Angle, -6 dB / 2 kHz, half space
  • Audio Connection 7" color-coded pigtails, pre-cut



Click to download
