Furman BB-RS232
BlueBOLT Ethernet To D9 RS232 Adaptor

OUR PART #:  BB-RS232

The BB-RS232 Adaptor from Furman provides Ethernet connectivity to BlueBOLT-supported Furman Sequencing products that are otherwise only capable of RS-232 communication.
Learn More
Our Price: $249.00
List Price: $249.95
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Furman BB-RS232
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The BB-RS232 Adaptor from Furman provides Ethernet connectivity to BlueBOLT-supported Furman Sequencing products that are otherwise only capable of RS-232 communication. The BB-RS232 Adaptor provides Ethernet connectivity to BlueBOLT-supported products that are otherwise only capable of RS-232 communication. Once the adaptor is connected between the BlueBOLT supported product (via RS-232) and the site’s Local Area Network (via Ethernet), the product can communicate with our BlueBOLT servers.

BlueBOLT allows you to:

  • Control individual outlets or outlet banks.
  • Monitor your devices and power status.
  • Receive email alerts for power events.
  • Schedule tasks such as power on, off, cycling, and sequencing.
  • Manage multiple devices in your chain of devices.
  • Utilize device-specific features for your compatible product.

Furman BB-RS232 Includes:

  • 3ft., 9-Conductor Cable for RS-232 Port
  • 6 ft., AC to DC Adaptor (12VDC)
  • Rack Screws

Furman BB-RS232 Features:

  • Communication Ports:
    • RS-232 with DSUB 9 Male connector. Pins 2 (RXD), 3 (TXD) and 5 (COM) are used for communication, pins 1 (GND) and 9 (+12V) are used for power.
    • 100BaseT Ethernet Communication with BlueBOLT service or a control system on the Local Area Network.
  • Indicators: For BlueBOLT connected, Status, Ethernet Link Status, and Data Activity.
  • Reset Button: Short press of Reset causes adaptor to reset the device. Holding down Reset for >10 seconds causes adaptor to revert to its default setting.
  • Power: Powered through non-communication signal wires of supplied 9-conductor cable (for RS232 port) or with included wide-range AC/DC switched-mode wall adaptor.
  • Mounting: Capable of being mounted to the rear equipment rack rail via its flange holes and supplied rack screws or on side of the equipment rack via the flange holes and zip-ties (not supplied).
