Biamp V2-215SW VERIS 2 Dual 15" Subwoofer, 400W, White

OUR PART #: VERIS2-215S-WHITE MFR #: V2-215SW

Copied to clipboard

The high output V2-215S is a dual-driver subwoofer system designed to augment and extend the low frequency output of any VERIS 2 full-range loudspeaker system... ...Read more

Biamp V2-215SW VERIS 2 Dual 15" Subwoofer, 400W, White Image 1
Biamp V2-215SW VERIS 2 Dual 15" Subwoofer, 400W, White
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The high output V2-215S is a dual-driver subwoofer system designed to augment and extend the low frequency output of any VERIS 2 full-range loudspeaker system, achieving the high impact and depth of response needed for larger venues. It is characterized by deep, dramatic bass and a fast transient response. Powerful and low in distortion, the V2-215S produces authoritative low frequency output and can handle

almost any musical style with ease. Solidly constructed of 18mm, 11-ply cross-laminated birch plywood, this subwoofer provides an accurate acoustic response uncolored by enclosure resonance.

The enclosure may be suspended from its M10 threaded rigging points, or simply located on the floor. As with all subwoofers, a corner placement is recommended when possible, in order to take advantage of the acoustical boundary effect for the highest possible efficiency. The V2-215S includes Community’s exclusive DYNA-TECH™ driver protection circuitry to protect against abusive operating conditions, and also features Community’s patented Cool-Coil™ heat evacuation technology to minimize cone driver power compression and ensure longterm reliability.

Community VERIS2 215S Features:

  • DYNA-TECH™ driver protection circuitry
  • Patented Cool-Coil™ heat evacuation technology tominimize cone driver power compression
  • Eight M10 threaded rigging fittings (four on each endpanel)
  • Built-in Ergo-Grip™ handles (two on each end panel)
  • Terminal strip and NL4-compatible connectors
  • Available in standard black or white finishes

Community VERIS2 215S Specifications:

  • Loudspeaker Type: Dual driver subwoofer, rectangular,vented bass
  • Operating Range: 37 Hz to 2000 Hz (-10 dB)
  • Frequency Response: 50 Hz to 1000 Hz (-3 dB)
  • Max Input Ratings:
    • 400W continuous, 1000W program
    • 40 volts RMS, 80 volts momentary peak
  • Sensitivity (1W/1m): 97 dB (50 Hz to 200 Hz) halfspace
  • Maximum Output: 123 dB SPL / 129 dB SPL (peak)
  • Nominal Impedance: 4 ohms
  • Minimum Impedance: 3.3 ohms @ 130 Hz
  • Nominal –6dB Beamwidth: 360° H x 180° V
  • Recommended Signal Processing: 35 Hz, 24 dB/octavehigh pass filter
  • Drivers: LF 2 x 15-inch
  • Driver Protection: DYNA-TECH protection circuitry
  • Input Connection: NL4-compatible locking connectorwith terminal strip in parallel
  • Controls: None
  • Enclosure: 18mm, 11-ply cross-laminated birch
  • Mounting/Rigging Provisions: 8 x M10 threaded riggingfittings
  • Finish: Catalyzed polyester two-part paint, black orwhite
  • Grille: Powder coated steel, black or white finish
  • Required Accessories: None
  • Supplied Accessories:
    • Rubber feet, black (4)
    • Built-in Ergo-Grip™ handles (4)
  • Optional Accessories:
    • M10EYBLTKIT 10mm eyebolt kit
    • STKIT seat track kit
  • Dimensions:
    • Height: 18.4 inches (468 mm) - not including feet
    • Width: 37.4 inches (950 mm)
    • Depth: 20.4 inches (518 mm)
  • Weight: 94 lbs (42.6 kg)
  • Model Options:
    • V2-215SB (black finish)
    • V2-215SW (white finish)
