Doug Fleenor Designs DMX96OC
DMX 96Ch Relays


The DMX96OC is designed to drive solenoids and relays for fountains or special effects, and is ideal for many other on/off loads.
Learn More
Our Price: $1,347.03
List Price: $1,663.00
You save 19%!
Be the first to review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping


We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price


Doug Fleenor Designs DMX96OC
In Stock

Similar Products

The DMX96OC is designed to drive solenoids and relays for fountains or special effects, and is ideal for many other on/off loads. The product decodes 96 consecutive DMX512 channels to drive open-collector NPN outputs. Each of the outputs is capable of sinking up to 100mA (or more based on duty cycle). The DMX512 input is optically isolated from the outputs and is protected against miswiring up to 120 volts. DFD also makes a single channel DIN rail mounted version model DININTR.

Doug Fleenor Designs DMX96OC Specifications:

  • Input baud rate:  DMX512: 250 Kb/s
  • Input circuit:  EIA-485 receiver with series100 ohm PTC self-resetting "fuses" clamped to +/- 7 volts by four lowcapacitance transorb diodes
  • Input signal:  0.5 volts minimum, 12 volts maximum
      -  Input can withstand up to 120volts without damage and transients up to 5KV
  • Output circuit:  8-bit 50V 500mA NPN Darlington driver
      -  Unprotected output
  • Output signal:  VCE(SAT) 1.1V maximum at 100mA
  • Max. output current:  100mA continuous, 500mApeak
  • Max. output voltage:  48VDC
  • Input/output isolation:  Greater than 500 volts
  • Throughput delay:  Less than .005 seconds (DMXinput change to output change)
  • DMX512 connectors:  Two gold plated 5 pin Neutrik D-1 Series(male input, female pass through)
      -  (All five pins are wired on the passthrough)
  • Output connectors:
      -  Four female DB-25 with goldplated pins
      -  Pin number equals output number, pin 25 isoutput common (900mA maximum on pin 25)
  • Output common:  An "output common" terminal blockis available for high current applications.
  • Power input:
      -  (Standard ) model: DMX96OC-EXTPS:Terminal block for user's external CLASS II power supply 12 - 24 volts DC200mA
     -  (Optional) model: DMX96OC: With 6' power cord 90 - 125 volts AC,50/60 hertz, 10 watts (240 volt optional)
  • Color:
      -  Top, bottom and sides: Silver hammertone
     -  Front and back: Black
  • Size and weight:  6.5" deep, 1.7" high, 16.5" wide, 6.5 pounds (19"rack adapter available)
Rack Kit
Doug Fleenor Designs RK16-1 Rack Kit
This unit is a rack kit; one 16" wide gray chassis in 1U.
