Doug Fleenor Designs 321E
DMX Merger, 3 In/ 1 Out, Isolated

OUR PART #:  321E

Want to pile-on two DMX512 sources? You can't just tie the outputs together like you can with 0 to 10 volt analog control signals.
Learn More
Selected Model Price: $1,747.20
List Price: $2,275.00
Save up to 23%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Doug Fleenor Designs 321E
Select a Model: (shipping times are approximate)
Qty:

Similar Products
Want to pile-on two DMX512 sources? You can't just tie the outputs together like you can with 0 to 10 volt analog control signals. Combining two DMX512 sources requires a computer, like the one in DFD's model 321E DMX Combine Unit. The combiner introduces the minimum delay possible with DMX512, less than 0.02 seconds. Combine units are available in up to six input configurations as standard products. For more than 6 inputs, multiple units can be linked together. These combiners feature terminated opto-isolated inputs which are also protected from AC line crosses and transients. Each input has an LED signal indicator. These combiners can also be used to convert to, or from, Colortran's CMX protocol (as used in D-192 series dimmers)

Doug Fleenor Designs 321E Specifications:

  • Baud rate:  250 Kilo baud
  • Input circuit:  EIA-485 receiver with 120 ohm termination between +data and -data
  • Input connectors: Gold plated 5 pin male (Neutrik D1series)
    • Terminal Block Optional
  • Output circuit: EIA-485 driver
  • Output connector: Gold plated 5 pin female (Neutrik D1series)
    • Terminal Block Optional
  • Input to output delay: 1/100 second average 1/50 second maximum
  • Power input: 100 - 120 volts, 50/60 hertz, 12 watts
    • (208 - 240 volt optional)
  • Power cord: Attached 5' 18/3 cord with parallel blade with groundplug.
  • Color: Silver hammertone with black front and back panels.
  • Size and weight (DxHxW):
    • Table Top: 11.25" x 1.74" x 8.25", 4.9 pounds (19" Rack Kits Available)
    • Wall Mount: 2" x 8.5" x 10.5", 5 pounds
      • Mounting Hole Locations 6" Vertical 9.5" Horizontal

NOTE: Product shown in image is for illustrative purposes only - actual product is 3 In/ 1 Out.

Rack Kit
Doug Fleenor Designs RK8-1 Rack Kit
This unit is an 8" wide 1U rack kit, allowing you to mount equipment in a standard rack.
