Tannoy ARENA-HL-500-LCR
Highline Speakers, 8000-5950


Call for price! Not available online.

The Arena HighLine 500c is designed primarily as a premium performance low profile, full range loudspeaker for use in conjunction with Plasma or LCD flat screens. The supplied bracket system and cable management ensure a close to wall mounting and a visual effect that blends with the décor; important in high style installations such as lounges, bars, hotels and boardrooms.

The HighLine 500c can be used as left, right and centre around the screen, while low frequency reinforcement can be provided by adding the Tannoy V Series VS10 BP subwoofer in conjunction with the TDX1 electronic system controller.

The frequency response is 83Hz to 62kHz (-10dB from rated sensitivity, measured on axis in an anechoic chamber) with no equalization. Sensitivity is 88.5dB at 1W @ 1metre (1W = 2.83V for 8 Ohms) and long-term power handling capacity (as defined in EIA-426B test) is 75W, while the recommended amplifier power is 150W. The nominal system impedance is 8 Ohms.

For maximum acoustic integrity of the drive units the already robust, thick walled aluminium extruded cabinet is further internally braced, with Tannoy DMT™ (Differential Material Technology) at strategic points throughout its length to minimise any cabinet resonance; this to ensure fully optimised reproduction.

Highline 500c is lavishly finished in high gloss silver or black and supplied with flush mounting hardware as standard. Optional accessory hardware includes a floor stand or table mount.


  • Recommended Amplifier Power 25 - 100W RMS
  • Maximum Sensitivity (2.83V @ 1m) 88dB
  • Nominal Impedance 8 Ohms
  • Frequency Response (-6dB) 75Hz- 54kHz
  • Crossover frequency 1.75kHz

Drive Units

  • Driver Type 1 x 100mm (4”) Dual Concentric™ with 19mm (0.75”) HF, 1 x 100mm (4”) LF
  • Magnetic Shielding Yes


  • Weight 14 kg (30.8 lbs)
  • Dimensions (H x W x D) 1161 x 209 x 197mm (45.69 x 8.23 x 7.76”)
  • Finish Gloss black, gloss silver
  • Supplied Accessories Floor coupling spikes and polished floor protectors
