Palmer PGA04
Speaker Simulator with 8 Ohm Loadbox


Our Price: $679.95
List Price: $1,121.95
You save 39%! (Low Price Guarantee)
Usually ships in 7-14 business days.
Need it sooner? Call us!

Special DI box with loadbox for guitars. The integrated load resistor permits tube amplifiers up to approximately 120 W to be connected to the PGA04, bypassing a loudspeaker. A jack socket (unbalanced) and balanced XLR connector are available for direct pickup of the signal. The extensive filter section provides for a realistic simulation of classic guitar loudspeaker sounds.


  • product type: speaker simulator
  • type: passive
  • Channels: 1
  • input type: unbalanced
  • Inputs: 1
  • input connectors: 6.3 mm Jack
  • dummy load: yes
  • dummy load impedance: 8 Ohm(s)
  • Outputs: 2 batteries
  • output connectors: 6.3 mm Jack, XLR
  • max. load: 100
  • output type: unbalanced, balanced
  • voicing filter: yes
  • output impedance: 10 k (6,3 mm Klinke), 600 (XLR) Ohm(s)
  • power attenuator: no
  • Display: max. load
  • controls: fullrange volume, high, volume, low, high cut, colour, ground lift, filter volume
  • transformer isolated outputs: yes
  • cabinet material: sheet steel
  • Cabinet / Housing surface: powder coated
  • width: 19 "
  • height: 1 U
  • width: 480 mm
  • depth: 180 mm
  • height: 44,5 mm
