Atlas Sound VTB-6
Horn Compression Driver, 70.7V

OUR PART #:  VTB-6

Atlas Sound VTB Series Models are environment-resistant loudspeakers designed for intercom communication.
Learn More
Our Price: $85.99
List Price: $106.99
You save 20%!
Write the first review.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Atlas Sound VTB-6
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

Atlas Sound VTB Series Models are environment-resistant loudspeakers designed for intercom communication. VTB Models feature an integral exponential horn to provide reliable sound distribution and optimum intelligibility for the reproduction of voice and/or electric tone signals. Units have a frequency response of 600 Hz to 5500 Hz ±5dB, and are offered in six models to meet application requirements. Series Models VTB-1 and VTB-2 are 8 and 4 ohm units, respectively. Models VTB-3 through VTB-6 are equipped with a built-in transformer. Termination is via 6" color coded leads. Units are of die-cast zinc construction with a water-sealed driver that will withstand moisture, corrosion, vibration, vermin, and vandalism. Models are available with a selection of multi-tap transformers and are designed to mount a variety of standard or custom housings and face plates to meet installation and application requirements. VTB Series units provide years of trouble-free service in stationary or mobile applications both indoors or outdoors.

Features:

  • 25 V
  • Communications, Intercom, Electronic Alarm, and Monitoring Systems
  • High Efficiency Compression Driver for Optimum Audio Intelligibility
  • Metal Die-Cast Construction with Integral Exponential Horn
  • Operates Within a Temperature Range of -30° F to 150° F
  • Patented Voice/Tone Loudspeaker for Custom Application in High Efficiency Industrial
  • Selection of five Models; 2 or 15 Watts, 4 or 8 Ohms, 25V or 70.7V Transformers
  • UL-Recognized Speaker Component
  • Water/Moisture, Corrosion, Dust, Vibration, and Vermin-Resistant

Specifications:

  • Height: 30 11/16" (9.36752 cm)
  • Width: 30 11/16" (9.36752 cm)
  • Depth: 30 3/16" (8.09752 cm)
  • Shipping Weight: 2.10 lbs (0.95 kgs)
  • Frequency Response: 600 Hz - 5500 Hz (± 5dB)
  • Power Handling: 15W (25V)
  • Sensitivity: 96.9dB (1W / 1M)
  • UL Listed/Standard: 1480 Recognized Component
