Audix L5 Micro-Sized Cardioid Lavalier Microphone

For the highest quality sound from the smallest possible package.

The L5 miniature cardioid condenser microphone is just 5 mm in diameter and is intended for use with the Audix wireless systems as well as hard-wired vocal and instrument applications. With a smooth and accurate frequency response of 40 Hz – 20 kHz and its small size, the L5 is ideal for broadcast and live sound applications including speech, interview, presentation, theatrical production, and instruments like acoustic guitar and violin. It is capable of accurately capturing and reproducing vocals from 4”-8” or acoustic instruments from 1”-2” away.

The L5 is manufactured to high standards and features a modular threaded capsule, a machined brass body with a matte black finish, and a high-quality shielded microphone cable.

Note: APS911 phantom power adapter required (not included).

Audix L5 Applications:

For use with Audix wireless bodypacks

Speech

Interviews

Presentation

Acoustic instruments

Audix L5 Includes:

• 1 x L5 Vocal Mic
• 1 x MCL5 Tie Clip
• 1 x WSL5 External Foam Windscreen
• 1 x P1 Carrying Pouch

Audix L5 Features:

• 5 mm modular capsules
• Broadcast quality
• Small, lightweight, low profile
• Natural, accurate sound reproduction
• Easy to use and set up

Audix L5 Specifications:

• Transducer Type: Pre-Polarized Condenser
• Frequency Response: 40 Hz – 20 kHz
• Polar Pattern: Cardioid
• Output Impedance: 200 ohms
• Sensitivity: 6 mV (C) / Pa @ 1k
• Equivalent Noise Level: < 31 dB (A-Weighted)
• Signal to Noise Ratio: > 63 dB
• Dynamic Range: 99 dB
• Maximum SPL: > 130 dB
• Power Requirements: 9-48 V Phantom Power
• Cable / Connector: Shielded 3’ (L5) terminating to a miniature 3 pin XLRf connector
• Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
• Material: Machined Brass
• Finish: Black
• Weight: 13 g (0.47 oz)
• Length: 23 mm (0.91")
