Speco Technologies CVC627VFSCS
Control Series Weatherproof Security Camera

OUR PART #  CVC627VFSCS

Our Price: $584.00
Usually ships in 7-14 business days.
Need it sooner? Call us!

A Speco Control Seried Weatherproof IR day/night color camera with varifocal lens.

FEATURES

  • Third-generation DSP chip
  • 1/3" Sony Super-HAD II CCD
  • True day/night capability with removable ICR-IR cut filter
  • High resolution - 550 TV lines: vivid sharp picture in complete darkness
  • 30 built-in IR LEDs with maximum range up to250' (depending on scene reflection)
  • Full on-screen display (OSD) controls
  • External focus & distance adjustment
  • Weatherproof operation
  • Easy mount bracket included
  • 5 year warranty

SPECIFICATIONS

  • Image Pick-Up Device - 1/3" Sony Super-HAD II CCD
  • TV System - NTSC
  • Effective Pixels - 768(H) x 494(V)
  • Resolution - 550 TV Line
  • Minimum Illumination - 0 lux (IR On) 0.005 lux (IR Off)
  • Lens: 2.8 - 12mm auto iris varifocal
  • Scanning Frequency - NTSC=15.734kHz(H) x 59.94Hz(V)
  • Scanning System - 2:1 Interlace
  • Synchronization - Internal
  • S/N Ratio - 52dB
  • White Balance - ATW/ATB/FIXED/MANUAL/OUTDOOR/INDOOR/AWC
  • Video Output -  CVBS: 1.0Vp-p 75ohm
  • Electronic Shutter Speed - NTSC= (1/60 sec ~ 1/100,000 sec,)
  • Digital Zoom -  On (x32)/Off
  • Mirror - H/V/Both/Off
  • Speco DNR - Off/On (1-100 level adjustable)
  • Sense Up - Auto/Off (x2 ~ x256 selectable)
  • Day/Night Setting - Color/Auto/BW
  • Display Adjust -  Contrast/Sharpness/CB-Gainer/CR-Gain
  • Privacy - On/Off (8 zone)
  • Power Supply - 24V AC / 12V DC - dual voltage operation
  • Power Consumption - 150mA (LED Off) max 600mA (LED On)
  • Operational Temperature: 20 degrees F to 120 degrees F
  • Operational Humidity: 95% max
  • Dimensions: 3.1" x 3" x 6.8" (WxHxL)
