Electro-Voice EVF1122D/126-WHITE
Single 12" Two-Way, 120° x 60°, Full-Range Loudspeaker System, White

OUR PART #:  EVF1122D/126-WHITE

EVF-1122D/126 features a 120° x 60° rotatable waveguide, design for near field widest throw coverage pattern.
Learn More
Our Price: $2,390.00

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Electro-Voice EVF1122D/126-WHITE
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

EVF-1122D/126 features a 120° x 60° rotatable waveguide, design for near field widest throw coverage pattern.

Features:

  • Color: WHITE (Not pictured)
  • Designed for Club Sound, Performance & Sports Venues, Stadium Systems, and other applications.
  • DH7N 3” (76 mm) diaphragm, 1.4” (36 mm) exit pure titanium compression driver
  • DVX3121A 12” (305 mm) LF transducer with fully symmetric drive
  • Advanced fourth-order crossover network with HF protection
  • Coverage pattern: 120° x 60° Constant DirectivityTM12” rotatable waveguide
  • 97 dB sensitivity, 131 dB maximum SPL
  • System rating: 600 W continuous, 2400 W peak
  • Active rating: LF 500 W/HF 75 W continuous (2000 W/300 W peak)
  • (22) M10 threaded suspension points
  • PI version available with gland nut and stainless-steel grille

Specifications:

  • Input Connections Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals
  • Frequency Response (-3 dB) 57 Hz - 18 k Hz
  • Frequency Response (-10 dB) 49 Hz - 21 k Hz
  • Recommended High-Pass Frequency 65 Hz
  • Sensitivity 1 W/1 m 97 dB
  • Max. SPL/1m (calc) 131 dB

Coverage

  • (Nominal -6 dB) H° 120 °

Coverage

  • (Nominal -6 dB) V° 60 °
  • System Power Handling (Continuous/Program/Peak) 600/1200/2400 Watts
  • LF Transducer DVX3121A, 12” (305 mm) driver
  • LF Nominal Impedance 8 O
  • HF Transducer DH7N, 3” (76 mm) diaphragm compression driver
  • Crossover Frequency 1300 Hz
  • Nominal Impedance (Passive) 8 O
  • Minimum Impedance 6 O
  • Enclosure Material 13-ply weather-resistant birch with EVCoat
  • Grill 16 GA powder-coated galvanneal with rotatable logo
  • Suspension (22) M10 threaded suspension points
  • Height 768.6 mm (30.26")
  • Width 406.3 mm (16")
  • Depth 413.3 mm (16.27")
  • Weight Net 29.7 kg (65.48 lbs)
  • Shipping Weight 34.4 kg (75.84 lbs)
