Midas DL351
7RU Modular I/O Box

OUR PART #:  DL351

Midas' DL351 is a 7RU, 19" W rack unit that can provide a maximum of 64 audio inputs and 64 audio outputs.
Learn More
Our Price: $2,999.99
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping


We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price


Midas DL351
In Stock

Similar Products

Midas' DL351 is a 7RU, 19" W rack unit that can provide a maximum of 64 audio inputs and 64 audio outputs.  It has the same user-configurable card format as the DL451 but has the capacity to house up to 8 cards, which can be any combination of 8 analogue mic/line in, 8 analogue out (XLR), 8 analogue TRS line level in and out, 8 digital in and out (4 AES/EBU pairs) or a 25-pin D sub card with 8 analogue mic/line inputs and 8 outputs.

MIDI in, out and thru, and GPIO connections are supplied as standard.  Digital audio interface is via 4 AES50 ports, one of which can be configured as a spare redundant connection.  Dual redundant power supplies with locking IEC connectors are fitted as standard.

The DL351 can be used with the Midas XL8 and PRO Series of digital mixing systems, or as a stand-alone AES50 audio interface in a Midas snake and audio distribution system with remote control via Ethernet.


  • 64 audio inputs
  • 64 audio outputs
  • Five card options of:
    - DL441 Analogue Mic / Line Input "I" card
    - DL442 Analogue Output "O" card
    - DL443 8 Analogue Line In and 8 Analogue Line Out "TRS" card
    - DL452 AES/EBU Input and Output "D" card
    - DL444 "D Sub" card, 8 analogue mic/line in, 8 line out
  • Midi in, out and thru
  • GPIO
  • Digital snake and distribution network component with redundant connections
  • Ethernet control port
I/O Blanking Plate, DL451/DL351
Midas DLIO-BP I/O Blanking Plate, DL451/DL351
I/O Blanking Plate for DL451 and DL351 I/O Rack
