Grass Valley ADVC-G2 HDMI/SDI to Analog and SDI Multi-Functional Converter/Downconverter with Frame Synchronizer

HDMI & SDI to Analog & SDI Multi-Functional Converter/Downconverter with Frame Synchronizer

Featuring HDMI and HD/SD-SDI (3G/1.5G support) for the inputs and HD/SD-SDI (3G/1.5G support), component, composite, S-Video, AES/EBU, and analog audio for the outputs, the new ADVC G2 plays the role of many converters for the price of one. The ADVC G2 also features 3G support, downconverting, and a frame synchronizer, which becomes very handy when, for example, connecting the SDI out to a switcher.

The ADVC G2 can be used as a monitoring device for HDMI and HD/SD-SDI sources, but it can also act as an HDMI to HD/SD-SDI (3G/1.5G support) converter.

The AES/EBU and analog audio outputs, used for audio de-embedding, are a welcome feature in most monitoring applications.

Grass Valley ADVC-G2 Features:

• Full 3G support (up to 60p)
• Integrated HDMI input
• Integrated frame synchronizer
• HDMI input for latest camcorder connections
• Audio output for audio de-embedding

Grass Valley ADVC-G2 Specifications:

• Inputs: (3G) HD/SD-SDI, HDMI, reference
• Input Formats:
  • 1080i60/59.94/50
  • 1080p60/59.94/50/30/29.97/25/24/23.98
  • 1080psf/24/23.98
  • 1035i60/59.94
  • 720p60/59.94/50/30/29.97/25/24/23.98
  • 480i/p 60/59.94
  • 576i/p50
• Outputs: (3G) HD/SD-SDI, component, composite, S-video, analog audio, AES/EBU
• Output Formats:
  • 1080i60/59.94/50
  • 1080psf23.98/24
  • 1080p60/59.94/50/30/29.97/25/24/
  • 23.98
  • 1035i60/59.94
  • 720p60/59.94/50/30/29.97/25/24/23.98
  • 480i 59.94
  • 576i50
• Dimensions: 142.5 x 42.5 x 98.5mm
