Electro-Voice EVF1152S/64-WHITE
Two-Way 15" Full-Range Loudspeaker, 500W @ 8ohms, 60X40 Degree Dispersion, White

OUR PART #:  EVF1152S/64-WHITE

Every EVF trapezoidal enclosure is constructed out of weather-resistant birch, and coated with EVCoat for maximum protection from the elements.
Learn More
Our Price: $1,989.00
Write the first review.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Electro-Voice EVF1152S/64-WHITE
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products
Every EVF trapezoidal enclosure is constructed out of weather-resistant birch, and coated with EVCoat for maximum protection from the elements. EVF‘s unique acoustic and rigging designs allow for vertical and horizontal clusters to be built using any combination of loudspeakers from both the entire EVF & EVH Series. With an assortment of full-range, low-frequency, and subwoofer loudspeakers, the EVF Series provides the tools to maximize the flexibility of system design, no matter what the application and budget. EVF‘s innovative input panels provide the choice of Phoenix-type connectors (included in all standard models), or allow the easy addition of a dual NL4-type connector cover plate or gland nut cover plate (for weatherizing applications). An externally accessible jumper also selects passive or active operation, and an available 70.7/100V transformer kit simply mounts to the input panel for use in distributed systems. All features provide the flexibility to manage more venues with less equipment, while quickly and precisely addressing customer requirements.

Features:

  • Designed for House of Worship, Performance & Sports Venues, Stadium Systems, and other applications.
  • ND2B 2” (51 mm) diaphragm, 1.4” (36 mm)
  • SMX2151 15” (381 mm) LF transducer with fully symmetric drive
  • Advanced fourth-order crossover network with HF protection
  • Coverage pattern: 60° x 40° Constant Directivity™ 12” rotatable waveguide
  • 101 dB sensitivity, 134 dB maximum SPL
  • System rating: 500 W continuous, 2000 W peak
  • Active rating: LF 400 W / HF 40 W continuous (1600 W / 160 W peak)
  • (22) M10 threaded suspension points
  • PI version available with gland nut and stainless steel grille

Specifications:

  • Input Connections Phoenix/Euroblock style screw terminals
  • Frequency Response (-3 dB) 70 - 14000 Hz
  • Frequency Response (-10 dB) 41 - 18000 Hz
  • Recommended High-Pass Frequency 45 Hz
  • Sensitivity 1 W/1 m 101 dB
  • Max. SPL/1m (calc) 134 dB
  • Coverage
    (Nominal -6 dB) H° 60 °
  • Coverage
    (Nominal -6 dB) V° 40 °
  • System Power Handling (Continuous/Program/Peak) 500 Watts
  • LF Transducer SMX2151, 15 in (381mm) Driver
  • HF Transducer ND2B, 2 in (51 mm) Diaphragm Compression Driver
  • Crossover Frequency 1450 Hz
  • Nominal Impedance (Passive) 8 O
  • Minimum Impedance 6 O
  • Enclosure Material 13 Ply Weather Resistant Birch
  • Grill 16 GA Galvanneal, Powdercoat, with Rotatable Logo
  • Suspension (22) M10 Threaded Points
  • Height 768.6 mm (30.26")
  • Width 469.8 mm (18.5")
  • Depth 466.6 mm (18.37")
  • Weight Net 32.1 kg (70.77 lbs)
