Kramer PT-572HDCP+
DVI over Twisted Pair Receiver


The Kramer PT-572HDCP+ is a twisted-pair receiver for DVI signals.
Learn More
Our Price: $156.00
List Price: $195.00
You save 20%!
Write the first review.
Kramer PT-572HDCP+
In Stock

Related Products

The Kramer PT-572HDCP+ is a twisted-pair receiver for DVI signals. The PT-571HDCP converts the DVI to twisted pair signal and the PT-572HDCP+ converts the twisted pair signal back to a DVI signal.

Kramer PT-572HDCP+ Features:

  • Max Data rate: 1365Gbps
  • HDTV comptaible
  • HDCP compliant
  • System Range
    • Up to 90m (295ft) at SXGA, or up to 30m (98ft) at UXGA on shielded BC-DGKat524 cable.
    • Up to 90m (295ft) at SXGA, or up to 70m (230ft) at UXGA on shielded BC-DGKat623cable.
    • Up to 100m (330ft) at SXGA, or up to 80m (265ft) at UXGA on shielded BC-DGKat723 cable.
  • Cable: Requires STP (shielded twisted pair) cable. For optimum range and performance, use Kramer's BC-DGKat524, BC-DGKat623 orBC-DGKat723 cables. Note that the transmission range depends on the signal resolution, graphics card and display used. The distance using non-Kramer CAT5, CAT 6, and CAT 7 cables may not reach these ranges
  • EDIDPassThru: Passes EDID/HDCP signals from source to display
  • PowerConnect System: A single connection to the transmitter or the receiver powers the system when the devices are within 270ft (90m) of each other
  • Ultra-Compact PicoTOOLS: 4 units can be rack mounted side-by-side in a 1U rack space with the optional RK-4PT rack adapter

Kramer PT-572HDCP+ Specifications:

  • Inputs: 1 RJ-45 connector
  • Outputs: 1 DVI, 1.2Vpp on a DVI Molex 24-pin female connector, DDC signal 5Vpp (TTL).
  • Bandwidth: Supports up to1.65Gbps
  • Power Source: 12V DC, 250mA
  • Dimensions: 2.4" x 2.1" x1"
